Yard-Man 3270
The Yard-Man 3270 is a tractor produced by Yard Man Lawn Tractors. It is equipped with a 275 cc 16.79 ci engine. The listed engine power is Gasoline (listed): 7 hp / 5.2 kW. Transmission: Peerless 600.
Engine Power
Gasoline (listed): 7 hp / 5.2 kW
Fuel & Capacities
Gasoline
Transmission
Peerless 600
Overview
 | 1969
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Yard-Man |
Lawn tractor | |
Built in Jackson, Michigan, USA | |
Yard-Man 3270 Engine | |
|---|---|
7HP Briggs & Stratton 275cc 1-cyl gasoline | |
Engine details ...  |
Yard-Man 3270 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Front tire | 13x4.00 |
Rear tire | 16x4.80/4.00-8 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Owners Operating Manual Model 3720-0 (0611-534A) published in 1968 |
Engine
Engine Detail — 275 cc / 16.79 ci Gasoline
Manufacturer | Briggs & Stratton 170702 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled |
Displacement | 275 cc
16.79 ci |
Bore/Stroke | 3.00x2.375 inches
76 x 60 mm |
Power | 7 hp
5.2 kW |
Starter type | manual recoil |
Transmission
Transmission — Peerless 600
Transmission | Peerless 600 |
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
Dimensions
Yard-Man 3270 Tires | |
|---|---|
Lawn/turf front | 13x4.00 |
Lawn/turf rear | 16x4.80/4.00-8 |
Dimensions |
|---|
Attachments
32" Mower deck | |
|---|---|
Type | mid-mount Yard-Man |
2-blade with manual lift | |
Cutting width | 32 inches
81 cm |
Photos
Yard-Man 3270 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Yard Man Lawn Tractors Yard-Man 3270.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Yard Man Lawn Tractors Yard-Man 3270 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Yard Man Lawn Tractors Yard-Man 3270.
Converted Equivalents:
Horsepower (HP)7 hp
Kilowatts (kW)5.2 kW
Metric Horsepower (PS / CV)7.1 PS
