Zanello 700
The Zanello 700 is a tractor produced by Zanello. It is equipped with a 855 ci 14.0 L engine. The listed engine power is Diesel (listed): 303 hp / 225.9 kW. Transmission: 12 forward and 4 reverse.
Engine Power
Diesel (listed): 303 hp / 225.9 kW
Transmission
12 forward and 4 reverse
Overview
 | 1992 - 2001
Four-wheel Drive (4WD) tractor |
|---|
Production | |
|---|---|
Manufacturer | Zanello |
Four-wheel Drive (4WD) tractor | |
Built in Argentina | |
Zanello 700 Engine | |
|---|---|
Cummins 14.0L 6-cyl diesel | |
Engine details ...  |
Zanello 700 Transmission | |
|---|---|
12-speed | |
Transmission details ...  |
Zanello 700 Power | |
|---|---|
Engine | 303 hp
225.9 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | hydraulic power |
Cab standard. | |
Hydraulics | |
|---|---|
Type | closed center |
Dimensions & Tires | |
|---|---|
Front tire | 23.1x30 |
Rear tire | 23.1x30 |
Full dimensions and tires ...  | |
Engine
Engine Detail — 855 ci / 14.0 L Diesel
Manufacturer | Cummins NT855-F2 |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled |
Displacement | 855 ci
14.0 L |
Bore/Stroke | 5.50x6.00 inches
140 x 152 mm |
Power | 303 hp
225.9 kW |
Starter type | electric |
Transmission
Transmission — 12 forward and 4 reverse
Gears | 12 forward and 4 reverse |
Dimensions
Zanello 700 Tires | |
|---|---|
Ag front | 23.1x30 |
Ag rear | 23.1x30 |
Dimensions |
|---|
Photos
Zanello 700
Zanello 700
Zanello 700
Zanello 700
Zanello 700C cab interior.
Recommended Implements & Sizing Guide
Engineering recommendations for Zanello 700 based on its 303 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 8+ Bottom On-Land Hitch8+ 铧重型机外牵引犁 | Commercial / Field Scale | High horsepower articulated/4WD field plowing. |
Rotary Cutter / MowerMowing & Clearing | 15 to 20 ft Batwing4.6 - 6.1 m 宽幅折叠翼 | Commercial / Field Scale | Large commercial field and roadside mowing operations. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 24 to 36 ft Heavy Duty Field Disc7.3 - 11.0 m 超宽重型整地耙 | Commercial / Field Scale | Broad-acre grain tillage for high-drawbar tractors. |
Hay BalerHay & Forage | Large Square Baler (3x4 or 4x4)大方捆商用打捆机 (1.2x1.2 m) | Commercial / Field Scale | High-capacity commercial forage harvesting (1000 RPM PTO). |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Zanello 700.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Zanello 700 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Zanello 700.
Converted Equivalents:
Horsepower (HP)303 hp
Kilowatts (kW)225.9 kW
Metric Horsepower (PS / CV)307.2 PS
Direct Competitor Comparison
Compare Zanello 700 against same-era industry alternatives in the same horsepower class.
Current Model
Zanello
Zanello 700
Engine Power:Diesel (listed): 303 hp / 225.9 kW
★ Baseline Reference
