Allis Chalmers FD3

The Allis Chalmers FD3 is a tractor produced by Allis Chalmers. It is equipped with a 99 ci 1.6 L engine. The listed engine power is Diesel (listed): 25 hp / 18.6 kW; Diesel (listed): 25 hp / 18.6 kW. Transmission: 8 forward and 4 reverse. Operating weight: 3,150 lbs 1428 kg.

Overview

Production
Manufacturer	Allis Chalmers
Built in France

Allis Chalmers FD3 Transmission
8-speed
Transmission details ...

Allis Chalmers FD3 Power
Engine	25 hp 18.6 kW

Mechanical
Two-wheel drive
Open operator station.

Power Take-off (PTO)
Rear PTO Type	540/1000
Mid PTO Type	1000

Dimensions & Tires
Weight	3,150 lbs 1428 kg
Front tire	450x16
Rear tire	10x28
Full dimensions and tires ...

References
FD3 published in 1962

Engine

Engine options
Vendeuvre 1.6L 2-cyl diesel
Perkins 1.6L 4-cyl diesel

Engine Detail — 95.8 ci / 1.6 L Diesel

Manufacturer	Vendeuvre Type 52
Fuel Type	Diesel
Configuration	2-cylinder, air-cooled
Displacement	95.8 ci 1.6 L
Bore/Stroke	3.937x3.937 inches 100 x 100 mm
Power	25 hp 18.6 kW
Rated RPM	2200
Oil capacity	7.4 qts 7.0 L

Engine Detail — 99 ci / 1.6 L Diesel

Manufacturer	Perkins 4.99
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	99 ci 1.6 L
Bore/Stroke	3.12x3.50 inches 79 x 89 mm
Power	25 hp 18.6 kW
Oil capacity	7.4 qts 7.0 L

Transmission

Transmission — 8 forward and 4 reverse

Gears	8 forward and 4 reverse
Clutch	dry disc

Dimensions

Allis Chalmers FD3 Tires
Ag front	450x16
Ag rear	10x28

Dimensions
Length	112.2 inches 284 cm
Height (steering wheel)	51.2 inches 130 cm
Weight	3,150 lbs 1428 kg
Front tread	44.5 to 60.6 inches 113 to 153 cm
Rear tread	50.4 to 65.75 inches 128 to 167 cm

Photos

Allis-Chalmers FD3, right-front view

Allis-Chalmers FD3, right-rear view

Allis-Chalmers FD3, detail of hood and grille

Rear view of the Allis-Chalmers FD3 showing hitch and PTO
