Allis Chalmers HB-112

The Allis Chalmers HB-112 is a tractor produced by Allis Chalmers Lawn Tractors. It is equipped with a 494 cc 30.16 ci engine. The listed engine power is Gasoline (listed): 12 hp / 8.9 kW. Transmission: infinite forward and reverse. Operating weight: 745 lbs 337 kg.

Overview

	1968 B SeriesGarden tractor B Series Garden tractor

Production
Manufacturer	Allis Chalmers
Garden tractor
Built in Lexington, South Carolina, USA

Allis Chalmers HB-112 Engine
12HP Briggs & Stratton 494cc 1-cyl gasoline
Engine details ...

Allis Chalmers HB-112 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Dimensions & Tires
Wheelbase	48 inches 121 cm
Weight	745 lbs 337 kg
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	starter-generator
Battery volts	12
Battery AH	40

References
Service Manual B Series Tractors (9003453) published in 1976

Engine

Engine Detail — 494 cc / 30.16 ci Gasoline

Manufacturer	Briggs & Stratton 300401
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled horizontal-shaft
Displacement	494 cc 30.16 ci
Bore/Stroke	3.25x3.44 inches 83 x 87 mm
Power	12 hp 8.9 kW
Air cleaner	oiled foam
Starter	electric
Starter volts	12
Oil capacity	2 qts 1.9 L

Transmission

Transmission — infinite forward and reverse hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse
Oil capacity	1.75 qts 1.7 L

Dimensions

Allis Chalmers HB-112 Tires

Dimensions
Wheelbase	48 inches 121 cm
Length	72 inches 182 cm
Width	40 inches 101 cm
Height (steering wheel)	37.75 inches 95 cm
Height (hood)	33.25 inches 84 cm
Shipping weight	745 lbs 337 kg
Clearance (front axle)	9 inches 22 cm
Clearance (rear axle)	6 inches 15 cm

Photos

Allis Chalmers HB-112 tractor photo
