Belarus 5170
The Belarus 5170 is a tractor produced by Belarus. It is equipped with a 289.9 ci 4.8 L engine. Transmission: 18 forward and 4 reverse. Operating weight: 6834 to 8201 pounds.
Fuel & Capacities
28.6 gal
108.3 L
Transmission
18 forward and 4 reverse
Operating Weight
6834 to 8201 pounds
Belarus 5170 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1994 - 1995
5100 Series |
|---|---|
1994 - 1995 | |
5100 Series | |
Production | |
|---|---|
Manufacturer | Belarus |
Belarus 5170 Engine | |
|---|---|
Belarus 4.8L 4-cyl diesel | |
Engine details ...  |
Belarus 5170 Transmission | |
|---|---|
18-speed | |
Transmission details ...  |
Belarus 5170 Power | |
|---|---|
PTO (claimed) | 74 hp
55.2 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | hydraulic rear lock |
Steering | hydrostatic power |
Mechanical dry disc brakes | |
Four-post ROPS. Cab optional. | |
Capacity | |
|---|---|
Fuel | 28.6 gal
108.3 L |
Hydraulic system | 4.8 gal
18.2 L |
Hydraulics | |
|---|---|
Type | live open center |
Capacity | 4.8 gal
18.2 L |
Pressure | 2800 psi
193.1 bar |
Valves | 2 |
Pump flow | 9.9 gpm
37.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 4400 lbs
1995 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 96.4 inches
244 cm |
Weight | 6834 to 8201 pounds |
Front tire | 9.0x20 |
Rear tire | 15.5x38 (2WD) |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 50 |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
Model 5170 published in 1995, by Belarus |
Engine
Engine Detail — 289.9 ci / 4.8 L Diesel
Manufacturer | Belarus D240 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 289.9 ci
4.8 L |
Bore/Stroke | 4.33x4.92 inches
110 x 125 mm |
Fuel system | direct injection |
Air cleaner | oil bath with pre-cleaner |
Compression | 16:1 |
Rated RPM | 2200 |
Idle RPM | 600-2385 |
Starter | electric |
Starter volts | 24 |
Oil capacity | 15.85 qts
15.0 L |
Coolant capacity | 20.1 qts
19.0 L |
Transmission
Transmission — 18 forward and 4 reverse
Gears | 18 forward and 4 reverse |
Clutch | dry disc |
Oil capacity | 42.27 qts
40.0 L |
Nine gears in two ranges. | |
Dimensions
Belarus 5170 Tires | |
|---|---|
Standard tires (ag) | Front: 9.0x20. Rear: 15.5x38 (2WD) |
Front: 11.2x20. Rear: 15.5x38 (4WD) | |
Dimensions | |
|---|---|
Wheelbase | 96.4 inches
244 cm |
Length | 154.7 inches
392 cm |
Width | 77.5 inches
196 cm |
Height (hood) | 64.4 inches
163 cm |
Height (cab) | 108.6 inches
275 cm |
Ground clearance | 18.3 inches
46 cm |
Front tread | 57.1 to 70.9 inches
145 to 180 cm |
Rear tread | 57.1 to 82.7 inches
145 to 210 cm |
Belarus 5170 Weight | |
|---|---|
2WD ROPS Shipping | 6834 lbs
3099 kg |
2WD Cab Shipping | 7650 lbs
3470 kg |
4WD ROPS Shipping | 7275 lbs
3299 kg |
4WD Cab Shipping | 8201 lbs
3719 kg |
Photos
Belarus 5170 tractor photo
