Belarus MTZ-80
The Belarus MTZ-80 is a tractor produced by Belarus. It is equipped with a 289.8 ci 4.7 L engine. The rated power output is 80 hp 59.7 kW. Transmission: 18 forward and 4 reverse. Operating weight: 7,840 lbs 3556 kg.
Engine Power
80 hp
59.7 kW
Fuel & Capacities
34.3 gal
129.8 L
Transmission
18 forward and 4 reverse
Operating Weight
7,840 lbs
3556 kg
Belarus MTZ-80 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1975 - 1977
Row-Crop tractor |
|---|---|
1975 - 1977 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Belarus |
Row-Crop tractor | |
Built in Minsk, Belarus | |
Variants | |
|---|---|
MTZ-80 | 2WD |
MTZ-82 | 4WD |
Belarus MTZ-80 Engine | |
|---|---|
MTZ 4.7L 4-cyl diesel | |
Engine details ...  |
Belarus MTZ-80 Transmission | |
|---|---|
18-speed | |
Transmission details ...  |
Belarus MTZ-80 Power | |
|---|---|
Engine | 80 hp
59.7 kW |
Drawbar (tested) | 62.34 hp
46.5 kW |
PTO (tested) | 74.79 hp
55.8 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | power assist |
Disc brakes | |
Cab standard. | |
Capacity | |
|---|---|
Fuel | 34.3 gal
129.8 L |
Hydraulic system | 5.6 gal
21.2 L |
Hydraulics | |
|---|---|
Capacity | 5.6 gal
21.2 L |
Pressure | 2321 psi
160.0 bar |
Total flow | 13.2 gpm
50.0 lpm |
Tractor hitch | |
|---|---|
Rear lift | 4,410 lbs
2000 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000/ground |
Dimensions & Tires | |
|---|---|
Wheelbase | 93.3 inches
236 cm |
Weight | 7,840 lbs
3556 kg |
Front tire | 7.50-20 |
Rear tire | 15.5-38 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Traktor-program published in 1979, by Belarus |
Engine
Engine Detail — 289.8 ci / 4.7 L Diesel
Manufacturer | MTZ D240 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 289.8 ci
4.7 L |
Bore/Stroke | 4.331x4.921 inches
110 x 125 mm |
Power | 80 hp
59.7 kW |
Air cleaner | oil bath |
Compression | 16:1 |
Rated RPM | 2200 |
Torque | 202.8 lb-ft
275.0 Nm |
Torque RPM | 1400 |
Starter volts | 12 |
Transmission
Transmission — 18 forward and 4 reverse
Gears | 18 forward and 4 reverse |
Clutch | dry disc |
Dimensions
Belarus MTZ-80 Tires | |
|---|---|
Ag front | 7.50-20 |
Ag rear | 15.5-38 |
Dimensions | |
|---|---|
Wheelbase | 93.3 inches
236 cm |
Length | 150 inches
381 cm |
Width | 77.6 inches
197 cm |
Height | 97.2 inches
246 cm |
Operating weight | 7,840 lbs
3556 kg |
Ballasted weight | 11,575 lbs
5250 kg |
Ground clearance | 18.3 inches
46 cm |
Front tread | 47.2 to 70.9 inches
119 to 180 cm |
Rear tread | 53.2 to 82.9 inches
135 to 210 cm |
Tests
Nebraska Tractor Test 1139 | |
|---|---|
Diesel 18-speed 2WD
August 28 - September 4, 1973
Link: Nebraska Tractor Test 1139 file | |
PTO performance | |
Power at rated engine speed | 74.79 hp
55.8 kW |
Fuel use | 4.9 gal/hour
18.5 l/hour |
Power at rated PTO speed | 73.88 hp
55.1 kW |
Fuel use | 4.8 gal/hour
18.2 l/hour |
Drawbar performance | |
Max power | 62.34 hp
46.5 kW |
Fuel use | 4.8 gal/hour
18.2 l/hour |
Gear 4H used for power test. | |
Max pull | 8,141 lbs
3692 kg |
Gear 2H used for pull test. | |
