CaseIH 4994

1984 - 1987

4WD 94 Series

Four-wheel Drive (4WD) tractor

Manufacturer

CaseIH

Four-wheel Drive (4WD) tractor

Built in Racine, Wisconsin, USA

Total built

224

Original price

$130,000 (1987)

Saab-Scania 14.2L 8-cyl diesel

12-speed full power shift

Engine

400 hp 298.3 kW

PTO (claimed)

344 hp 256.5 kW

Drawbar (tested)

294.24 hp 219.4 kW

PTO (tested)

344 hp 256.5 kW

Drive

4x4 4WD

Steering

hydraulic, front, rear or four-wheel crab steering

Hydraulic dual caliper disc brakes

Silent Guardian cab standard

Fuel

300 gal 1135.5 L

Hydraulic system

26.5 gal 100.3 L

Front hubs

13.5 qts (each) 12.8 L

Front diff.

17 qts 16.1 L

Rear hubs

13.5 qts (each) 12.8 L

Rear diff.

22.5 qts 21.3 L

Type

closed center

Capacity

26.5 gal 100.3 L

Pressure

2000 psi 137.9 bar

Valves

4

Total flow

35 gpm 132.5 lpm

Steering flow

20 gpm 75.7 lpm

Steering press.

2000 psi 137.9 bar

Rear PTO

independent (optional)

Rear PTO Type

1000

Engine RPM

1000@2100

Wheelbase

124.8 inches 316 cm

Weight

26500 to 31315 pounds

Front tire

24.5-32

Rear tire

24.5-32

Ground

negative

Charging system

alternator

Charging amps

105

Batteries

2

Battery volts

12

Battery AH

300

Battery Group

30H

4-Wheel Drive Tractors published in 1987, by CaseIH

1985 Farm Equipment Buyer's Guide published by CaseIH

Manufacturer

Saab-Scania

Configuration

turbocharged diesel, 8-cylinder, liquid-cooled

Displacement

866 ci 14.2 L

Bore/Stroke

5.00x5.51 inches 127 x 140 mm

Power

400 hp 298.3 kW

Air cleaner

dual paper elements

Compression

15.5:1

Rated RPM

2100

Torque

1140 lb-ft 1545.8 Nm

Torque RPM

1300

Firing order

1-5-4-2-6-3-7-8

Starter volts

12

Coolant capacity

88 qts 83.3 L

Intake valve clearance

0.018 inches 0.457 mm

Exhaust valve clearance

0.031 inches 0.787 mm

Oil capacity

27 qts 25.6 L

Type

full power shift

Gears

12 forward and 2 reverse

Clutch

hydraulic wet disc

Oil capacity

63 qts 59.6 L

59 qts (without PTO) 55.8 L

Oil type

Case Powergard PTF

Electronically-controlled Case power shift transmission operated with single control lever and inching pedal. The inching pedal must be depressed to move from park/neutral into first gear. Tractor must be moving in first gear before higher gears can be selected. Gear changes made by pushing control lever into upshift or downshift position. Control lever can be held in upshift/downshift position for multiple gear changes.

With 20.5-32 tires

Ag front

24.5-32

Ag rear

24.5-32

Ag front

20.8-38

20.8-42

23.1-34

30.5-32

Ag rear

20.8-38

20.8-42

23.1-34

30.5-32

Wheelbase

124.8 inches 316 cm

Length

261.8 inches 664 cm

Width

117 inches (minimum) 297 cm

156 inches (duals) 396 cm

Height (exhaust)

138.5 inches 351 cm

Clearance (drawbar)

14.5 inches 36 cm

Shipping

26,500 lbs 12020 kg

Operating

31,315 lbs 14204 kg

Ballasted

39,930 lbs 18112 kg

Max capacity

40,000 lbs 18144 kg

Diesel 12-speed 4WD June 9 - 27, 1984 Link: Nebraska Tractor Test 1530 file

PTO performance

Power at rated engine speed

344 hp 256.5 kW

Fuel use

20.2 gal/hour 76.5 l/hour

Drawbar performance

Max power

294.24 hp 219.4 kW

Fuel use

20.1 gal/hour 76.1 l/hour

Gear 6 used for power test.

Max pull

34,519 lbs 15657 kg

Gear 2 used for pull test.
