CaseIH 956 XL
The CaseIH 956 XL is a tractor produced by Caseih. It is equipped with a 358 ci 5.9 L engine. The rated power output is 95 hp 70.8 kW. Transmission: IH-Total-synchron. Operating weight: 9458 to 10300 pounds.
Engine Power
95 hp
70.8 kW
Fuel & Capacities
Diesel
Transmission
IH-Total-synchron
Operating Weight
9458 to 10300 pounds
Caseih 956 XL Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1985 - 1992
Utility tractor |
|---|---|
1985 - 1992 | |
Utility tractor | |
Production | |
|---|---|
Manufacturer | CaseIH |
Utility tractor | |
Built in Neuss, Germany | |
CaseIH 956 XL Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Engine details ...  |
CaseIH 956 XL Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
CaseIH 956 XL Power | |
|---|---|
Engine | 95 hp
70.8 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with heat. Air-conditioning optional. |
Hydraulics | |
|---|---|
Pressure | 2538 psi
175.0 bar |
Valves | up to 3 |
Pump flow | 11.4 gpm
43.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift | 9532 lbs
4323 kg |
11530 lbsOptOptional
5230 kg | |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 103.5 inches
262 cm |
4WD Wheelbase | 102 inches
259 cm |
Weight | 9458 to 10300 pounds |
Front tire | 7.50-20 |
Rear tire | 16.9R38 (2WD) |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 55 |
Battery volts | 12 |
References | |
|---|---|
 | |
856XL - 956LX - 1056XL published by CaseIH | |
856XL - 956LX - 1056XL published in 1985, by CaseIH |
Engine
Engine Detail — 358 ci / 5.9 L Diesel
Manufacturer | International Harvester D-358 |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 358 ci
5.9 L |
Bore/Stroke | 3.875x5.0625 inches
98 x 129 mm |
Power | 95 hp
70.8 kW |
Fuel system | direct injection |
Rated RPM | 2200 |
Torque | 261.8 lb-ft
355.0 Nm |
Torque RPM | 1400 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 12.7 qts
12.0 L |
Oil change | 200 h |
Transmission
Transmission — IH-Total-synchron
Transmission | IH-Total-synchron |
Gears | 16 forward and 8 reverse |
With 16.9R38 rear tires. | |
 | |
Dimensions
CaseIH 956 XL Tires | |
|---|---|
Standard tires (ag) | Front: 7.50-20. Rear: 16.9R38 (2WD) |
Front: 12.4R28. Rear: 16.9R38 (4WD) | |
Dimensions | |
|---|---|
2WD Wheelbase | 103.5 inches
262 cm |
4WD Wheelbase | 102 inches
259 cm |
2WD Length | 165.1 inches
419 cm |
4WD Length | 167.7 inches
425 cm |
Width | 90.8 inches
230 cm |
Height (cab) | 109.1 inches
277 cm |
2WD Weight | 9458 lbs
4290 kg |
4WD Weight | 10300 lbs
4672 kg |
2WD Clearance (front axle) | 20.2 inches
51 cm |
4WD Clearance (front axle) | 17.2 inches
43 cm |
2WD Front tread | 60.1 to 95.2 inches
152 to 241 cm |
4WD Front tread | 64.3 to 76.1 inches
163 to 193 cm |
Rear tread | 67.1 to 86.8 inches
170 to 220 cm (4WD) |
Photos
CaseIH 956 XL
