CaseIH Farmall DX18E

The CaseIH Farmall DX18E is a tractor produced by Caseih. It is equipped with a 58.2 ci 1.0 L engine. The listed engine power is Diesel (gross): 18 hp / 13.4 kW. Transmission: infinite forward and reverse (2-range). Operating weight: 1314 lbs 596 kg.

Engine Power

Diesel (gross): 18 hp / 13.4 kW

Fuel & Capacities

7.9 gal 29.9 L

Transmission

infinite forward and reverse (2-range)

Operating Weight

1314 lbs 596 kg

Overview

	2004 - 2008 DXE SeriesSub-Compact Utility tractor DXE Series Sub-Compact Utility tractor

Production
Manufacturer	CaseIH
Sub-Compact Utility tractor

Variants
TZ18DA	similar New Holland model

CaseIH Farmall DX18E Engine
Shibaura 1.0L 3-cyl diesel
Fuel tank	7.9 gal 29.9 L
Engine details ...

CaseIH Farmall DX18E Transmission
hydrostatic
Transmission details ...

CaseIH Farmall DX18E Power
Engine (gross)	18 hp 13.4 kW
PTO (claimed)	13.7 hp 10.2 kW

Mechanical
Four-wheel drive
Power steering
Two-post fixed ROPS. Canopy and soft cab optional.

Hydraulics
Type	open center
Pump flow	3.75 gpm 14.2 lpm
Total flow	5.5 gpm 20.8 lpm
Steering flow	1.85 gpm 7.0 lpm

Tractor hitch
Rear Type	I
Rear lift (at 24"/610mm)	700 lbs 317 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540 (1.375)
Mid PTO	independent
Mid PTO Type	2200

Dimensions & Tires
Wheelbase	55 inches 139 cm
Weight	1314 lbs 596 kg
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

DX Series Farmall Tractors published in 2004, by CaseIH
DX Series Farmall Tractors published in 2003, by CaseIH
DX Series Farmall Tractors and Integrated Implements published in 2004, by CaseIH

Engine

Engine Detail — 58.2 ci / 1.0 L Diesel

Manufacturer	Shibaura S753
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled inline
Displacement	58.2 ci 1.0 L
Bore/Stroke	2.953x2.835 inches 75 x 72 mm
Power (gross)	18 hp 13.4 kW
Compression	24:1
Rated RPM	3000
Idle RPM	1380-3200
Firing order	1-2-3
Starter volts	12

Transmission

Transmission — infinite forward and reverse (2-range) hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse (2-range)

Dimensions

CaseIH Farmall DX18E Tires

Dimensions
Wheelbase	55 inches 139 cm
Length	96.3 inches 244 cm
Width	45.9 inches 116 cm
Height (ROPS)	72.7 inches 184 cm
Weight	1314 lbs 596 kg

Attachments

Attachment overview
54" mid-mount mower deck
60" mid-mount mower deck
Snowblower
Blade
Front-end loader

Photos

CaseIH Farmall DX18E

Case IH Farmall DX18E operator station and controls.

Recommended Implements & Sizing Guide

Engineering recommendations for Caseih Farmall DX18E based on its 18 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Caseih Farmall DX18E.

Estimated Continuous Field Runtime: 8.4 hrs

Approximately 8.4 hours of continuous field operation at ~75% rated power on a full tank (7.9 gal / 29.9 L).

Estimated 75% Load Fuel Burn~0.9 gal/hr (3.5 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
