Challenger MT565E
The Challenger MT565E is a tractor produced by Challenger. It is equipped with a 402 ci 6.6 L engine. The rated power output is 185 hp 138.0 kW. Transmission: TechStar.
Engine Power
185 hp
138.0 kW
Fuel & Capacities
114 gal
431.5 L
Transmission
TechStar
Challenger MT565E Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2015 - 2020
MT500E SeriesRow-Crop tractor |
|---|---|
2015 - 2020 | |
MT500E Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Challenger (a part of AGCO) |
Row-Crop tractor | |
Built in Jackson, Minnesota, USA | |
Variants | |
|---|---|
7720 | similar Massey Ferguson model |
Challenger MT565E Engine | |
|---|---|
AGCO Power 6.6L 6-cyl diesel | |
Engine details ...  |
Challenger MT565E Power | |
|---|---|
Engine (gross) | 185 hp
138.0 kW |
Engine (max) | 225 hp
167.8 kW |
PTO (claimed) | 155 hp
115.6 kW |
Drawbar (tested) | 138.9 hp
103.6 kW |
PTO (tested) | 198.7 hp
148.2 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | electro-hydraulic front and rear |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. Auto-Guide 3000 | |
Capacity | |
|---|---|
Fuel | 114 gal
431.5 L |
Exhaust fluid (DEF) | 11 gal
41.6 L |
Hydraulic system | 26.4 gal
99.9 L |
Hydraulics | |
|---|---|
Type | closed-center load sensing |
Capacity | 26.4 gal
99.9 L |
Pressure | 2900 psi
200.0 bar |
Valves | 4 |
SCV flow | 26.4 gpm
99.9 lpm |
Total flow | 29 gpm
109.8 lpm |
39 gpm*Optional with AutoPower VI
147.6 lpm | |
50 gpm*Optional with CVT
189.2 lpm | |
Tractor hitch | |
|---|---|
Rear Type | III/IIIN |
Rear lift (at ends) | 13500 lbs
6123 kg |
16700 lbs*Lift capacity with CVT transmission.
7575 kg | |
Front Hitch | IIIN OptOptional |
Front lift (at ends) | 7954 lbs
3607 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/540E/1000 |
540E/1000E/1000 OptOptional | |
540/540E/1000/1000E *With CVT transmission. | |
Dimensions & Tires | |
|---|---|
Wheelbase | 117 inches
297 cm |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
MT500E Series Tractors published in 2015, by AGCO |
Engine
Engine Detail — 402 ci / 6.6 L Diesel
Manufacturer | AGCO Power |
Configuration | turbocharged intercooled diesel, 6-cylinder, liquid-cooled |
Displacement | 402 ci
6.6 L |
Bore/Stroke | 4.252x4.724 inches
108 x 120 mm |
Emissions | Tier IV |
Emission control | selective catalytic reduction (SCR) |
Rated Power (gross) | 185 hp
138.0 kW |
Maximum Power (gross) | 225 hp
167.8 kW |
Air cleaner | dry element |
Compression | 17.4:1 |
Rated RPM | 2100 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
24-speed six-speed power shift | |
continuously-variable transmission (CVT) |
Transmission — AutoPower VI
Transmission | AutoPower VI |
Type | six-speed power shift |
Gears | 24 forward and reverse |
Transmission — TechStar
Transmission | TechStar |
Type | continuously-variable transmission (CVT) |
Gears | infinite forward and reverse |
Dimensions
Challenger MT565E Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 117 inches
297 cm |
Tests
Tractor Tests | |
|---|---|
OECD 2949: diesel CVT 4WD | |
OECD 2947: diesel AutoPower VI 4WD |
OCED Tractor Test 2949 | |
|---|---|
Diesel CVT 4WD
2/2016
Link: OCED Tractor Test 2949 file | |
PTO performance | |
Max power | 198.7 hp
148.2 kW |
Fuel use | 10.6 gal/hour
40.1 l/hour |
Power at rated engine speed | 178.8 hp
133.3 kW |
Fuel use | 10.1 gal/hour
38.2 l/hour |
Power at rated PTO speed | 197.8 hp
147.5 kW |
Fuel use | 10.7 gal/hour
40.5 l/hour |
Drawbar performance | |
Max power | 138.9 hp
103.6 kW |
Fuel use | 10.0 gal/hour
37.9 l/hour |
Pull at 7.54KPH | |
Max pull | 16120 lbs
7312 kg |
Pull at 2.7KPH | |
OCED Tractor Test 2947 | |
|---|---|
Diesel AutoPower VI 4WD
February 2016 - March 2016,
Link: OCED Tractor Test 2947 file | |
PTO performance | |
Max power | 191.0 hp
142.4 kW |
Fuel use | 10.1 gal/hour
38.2 l/hour |
Power at rated engine speed | 167.3 hp
124.8 kW |
Fuel use | 9.5 gal/hour
36.0 l/hour |
Power at rated PTO speed | 181.6 hp
135.4 kW |
Fuel use | 10.0 gal/hour
37.9 l/hour |
Drawbar performance | |
Max power | 137.2 hp
102.3 kW |
Fuel use | 9.5 gal/hour
36.0 l/hour |
Gear 3A used for power test. | |
Max pull | 16300 lbs
7393 kg |
Gear 1B used for pull test. | |
Photos
Challenger MT565E tractor photo
