Craftsman Professional 944.10108

The Craftsman Professional 944.10108 is a tractor produced by Craftsman Professional Lawn Tractors. It is equipped with a 747 cc 45.6 ci engine. The listed engine power is Gasoline (gross): 26 hp / 19.4 kW. Transmission: Hydro-Gear G7.

Engine Power

Gasoline (gross): 26 hp / 19.4 kW

Fuel & Capacities

Gasoline

Transmission

Hydro-Gear G7

Overview

	2017 Garden tractorHusqvarna built Garden tractor Husqvarna built

Production
Distributor	Craftsman Professional (a part of Sears)
Manufacturer	Husqvarna
Garden tractor

Craftsman Professional 944.10108 Engine
19.4KW Kohler 747cc 2-cyl gasoline
Engine details ...

Craftsman Professional 944.10108 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric
Mid PTO Type	pulley

Dimensions & Tires
Front tire	16x6.5-8
Rear tire	23x10.5-12
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

Lawn & Garden published in 2017, by Sears

Engine

Engine Detail — 747 cc / 45.6 ci Gasoline

Manufacturer	Kohler KT745
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Displacement	747 cc 45.6 ci
Bore/Stroke	3.3x2.7 inches 84 x 69 mm
Power (gross)	26 hp 19.4 kW
Starter	electric
Starter volts	12

Transmission

Transmission — Hydro-Gear G7

Transmission	Hydro-Gear G7
Type	belt-driven hydrostatic
Gears	infinite forward and reverse

Dimensions

Craftsman Professional 944.10108 Tires
Lawn/turf front	16x6.5-8
Lawn/turf rear	23x10.5-12

Dimensions

Attachments

54" Mower deck
Type	mid-mount Craftsman
	3-blade with manual lift
Cutting width	54 inches 137 cm

Photos

Craftsman Professional 944.10108 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Craftsman Professional Lawn Tractors Craftsman Professional 944.10108 based on its 26 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Professional Lawn Tractors Craftsman Professional 944.10108.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Craftsman Professional Lawn Tractors Craftsman Professional 944.10108 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Professional Lawn Tractors Craftsman Professional 944.10108.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)26 hp

Kilowatts (kW)19.4 kW

Metric Horsepower (PS / CV)26.4 PS
