Cub Cadet C-130G

The Cub Cadet C-130G is a tractor produced by Cub Cadet Lawn Tractors. The listed engine power is Gasoline (gross): 13 hp / 9.7 kW. Transmission: Transmatic. Operating weight: 465 lbs 210 kg.

Engine Power
Gasoline (gross): 13 hp / 9.7 kW
Fuel & Capacities
1.5 gal 5.7 L
Transmission
Transmatic
Operating Weight
465 lbs 210 kg

Overview

Cub Cadet C-130G tractor photo
2000 - 2001 Lawn tractor
Production
Manufacturer
Cub Cadet (a part of MTD)
Lawn tractor
Cub Cadet C-130G Engine
9.7KW Briggs & Stratton 1-cyl gasoline
Fuel tank
1.5 gal 5.7 L
Engine details ...
Cub Cadet C-130G Transmission
8-speed CVT
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Power Take-off (PTO)
Mid PTO
independent
Clutch
electric
Dimensions & Tires
Weight
465 lbs 210 kg
Front tire
15x6
Rear tire
20x8
Full dimensions and tires ...
Electrical
Ground
negative
Battery volts
12
References
C-130G references literature
Lawn Tractors published in 2000, by Cub Cadet

Engine

Engine Detail — Gasoline

Manufacturer
Briggs & Stratton
Fuel Type
Gasoline
Configuration
1-cylinder, air-cooled vertical-shaft
Power (gross)
13 hp 9.7 kW
Starter
electric
Starter volts
12

Transmission

Transmission — Transmatic

Transmission
Transmatic
Type
belt-driven CVT
Gears
8 forward and reverse

Dimensions

Cub Cadet C-130G Tires
Lawn/turf front
15x6
Lawn/turf rear
20x8
Dimensions
Weight
465 lbs 210 kg

Attachments

38" Mower deck
Type
mid-mount Cub Cadet
2-blade with manual lift
Cutting width
38 inches 96 cm

Photos

Cub Cadet C-130G tractor photo

Cub Cadet C-130G tractor photo

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Cub Cadet Lawn Tractors Cub Cadet C-130G.

Estimated Continuous Field Runtime: 2.2 hrs

Approximately 2.2 hours of continuous field operation at ~75% rated power on a full tank (1.5 gal / 5.7 L).

Estimated 75% Load Fuel Burn~0.7 gal/hr (2.6 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Cub Cadet Lawn Tractors Cub Cadet C-130G Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Cub Cadet Lawn Tractors Cub Cadet C-130G.

Converted Equivalents:

Horsepower (HP)13 hp
Kilowatts (kW)9.7 kW
Metric Horsepower (PS / CV)13.2 PS
