Cub Cadet C-160G
The Cub Cadet C-160G is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The rated power output is 16 hp 11.9 kW. Transmission: Transmatic. Operating weight: 465 lbs 210 kg.
Engine Power
16 hp
11.9 kW
Fuel & Capacities
1.5 gal
5.7 L
Transmission
Transmatic
Operating Weight
465 lbs
210 kg
Cub Cadet Lawn Tractors Cub Cadet C-160G Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2000 - 2001
Lawn tractor |
|---|---|
2000 - 2001 | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Lawn tractor | |
Variants | |
|---|---|
C-160G | CVT |
C-160H | hydrostatic |
Cub Cadet C-160G Engine | |
|---|---|
11.9KW Briggs & Stratton 465cc 1-cyl gasoline | |
Fuel tank | 1.5 gal
5.7 L |
Engine details ...  | |
Cub Cadet C-160G Transmission | |
|---|---|
8-speed CVT | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Weight | 465 lbs
210 kg |
Front tire | 15x6 |
Rear tire | 20x8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn Tractors published in 2000, by Cub Cadet |
Engine
Engine Detail — 465 cc / 28.4 ci Gasoline
Manufacturer | Briggs & Stratton 311777 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 465 cc
28.4 ci |
Power (gross) | 16 hp
11.9 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Transmatic
Transmission | Transmatic |
Type | belt-driven CVT |
Gears | 8 forward and reverse |
Eight-position speed control lever. | |
Dimensions
Cub Cadet C-160G Tires | |
|---|---|
Lawn/turf front | 15x6 |
Lawn/turf rear | 20x8 |
Dimensions | |
|---|---|
Weight | 465 lbs
210 kg |
Attachments
42" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
2-blade with manual lift | |
Cutting width | 42 inches
106 cm |
