Cub Cadet LT 2138
The Cub Cadet LT 2138 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 426 cc 26 ci engine. The listed engine power is Gasoline (gross): 16 hp / 11.9 kW. Transmission: infinite forward and reverse. Operating weight: 100 lbs 45 kg.
Overview
 | 2003 - 2004
2000 SeriesLawn tractor
2000 Series
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Lawn tractor | |
Cub Cadet LT 2138 Engine | |
|---|---|
16HP Kohler 426cc 1-cyl gasoline | |
Fuel tank | 2.25 gal
8.5 L |
Engine details ...  | |
Cub Cadet LT 2138 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 47 inches
119 cm |
Weight | 565 lbs
256 kg |
Front tire | 15x6-8 |
Rear tire | 20x9-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 15 |
Battery CCA | 275 |
Battery volts | 12 |
References | |
|---|---|
 | |
Outdoor Power Equipment published in 2004, by Cub Cadet |
Engine
Engine Detail — 426 cc / 26 ci Gasoline
Manufacturer | Kohler CH16S |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled horizontal-shaft |
Displacement | 426 cc
26 ci |
Bore/Stroke | 3.54x2.64 inches
90 x 67 mm |
Power (gross) | 16 hp
11.9 kW |
Rated RPM | 3350 |
Idle RPM | 1400-3600 |
Torque | 25 lb-ft
33.9 Nm |
Starter | electric |
Starter volts | 12 |
Oil capacity | 2 qts
1.9 L |
Transmission
Transmission — infinite forward and reverse shaft-driven hydrostatic
Type | shaft-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 7 qts
6.6 L |
 | |
Dimensions
Cub Cadet LT 2138 Tires | |
|---|---|
Lawn/turf front | 15x6-8 |
Lawn/turf rear | 20x9-12 |
Dimensions | |
|---|---|
Wheelbase | 47 inches
119 cm |
Length | 72 inches
182 cm |
Weight | 565 lbs*Weight with 38-inch deck.
256 kg |
Attachments
38" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
2-blade | |
Cutting width | 38 inches
96 cm |
Weight | 100 lbs
45 kg |
Cut height | 2 to 4 inch
5 to 10 cm |
Photos
Cub Cadet LT 2138 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Cub Cadet Lawn Tractors Cub Cadet LT 2138 based on its 16 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Cub Cadet Lawn Tractors Cub Cadet LT 2138.
Estimated Continuous Field Runtime: 2.8 hrs
Approximately 2.8 hours of continuous field operation at ~75% rated power on a full tank (2.3 gal / 8.5 L).
Engine Crankcase Oil
Transmission & Hydraulic System
Engine Cooling System
Cub Cadet Lawn Tractors Cub Cadet LT 2138 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Cub Cadet Lawn Tractors Cub Cadet LT 2138.
Converted Equivalents:
Direct Competitor Comparison
Compare Cub Cadet LT 2138 against same-era industry alternatives in the same horsepower class.
Cub Cadet LT 2138
