Cub Cadet XT1 LT50
The Cub Cadet XT1 LT50 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 725 cc 44.24 ci engine. The rated power output is 24 hp 17.9 kW. Transmission: Tuff Torq K46. Operating weight: 500 lbs 226 kg.
Engine Power
24 hp
17.9 kW
Fuel & Capacities
3 gal
11.4 L
Transmission
Tuff Torq K46
Operating Weight
500 lbs
226 kg
Cub Cadet Lawn Tractors Cub Cadet XT1 LT50 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2015 -
XT1 Enduro SeriesLawn tractor |
|---|---|
2015 - | |
XT1 Enduro Series | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Lawn tractor | |
Original price was $2,000 in 2015 | |
Cub Cadet XT1 LT50 Engine | |
|---|---|
24HP Kohler 725cc 2-cyl gasoline | |
Fuel tank | 3 gal
11.4 L |
Engine details ...  | |
Cub Cadet XT1 LT50 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Disc brakes | |
Open operator station. Optional sunshade. Optional soft-side weather cab. | |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 47 inches
119 cm |
Weight | 500 lbs
226 kg |
Front tire | 15x6 |
Rear tire | 20x8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | flywheel alternator |
Charging amps | 12 |
Battery CCA | 230 |
Battery volts | 12 |
References | |
|---|---|
 | |
New XT Enduro Series Lawn and Garden Tractors published in 2015, by Cub Cadet | |
Lawn and Garden Tractors published in 2016, by Cub Cadet |
Engine
Engine Detail — 725 cc / 44.24 ci Gasoline
Manufacturer | Kohler KT735 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 725 cc
44.24 ci |
Bore/Stroke | 3.3x2.6 inches
84 x 66 mm |
Power (gross) | 24 hp
17.9 kW |
Starter | electric |
Starter volts | 12 |
Oil capacity | 2 qts
1.9 L |
Transmission
Transmission — Tuff Torq K46
Transmission | Tuff Torq K46 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
Cub Cadet XT1 LT50 Tires | |
|---|---|
Lawn/turf front | 15x6 |
Lawn/turf rear | 20x8 |
Dimensions | |
|---|---|
Wheelbase | 47 inches
119 cm |
Length | 68 inches
172 cm |
Height | 42.5 inches
107 cm |
Weight | 500 lbs
226 kg |
Front axle | Cast-iron |
Attachments
Attachment overview | |
|---|---|
50" mid-mount mower deck | |
Snowblower | |
Blade |
50" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
3-blade with manual with spring-assist lift | |
Cutting width | 50 inches
127 cm |
Overall width | 60 inches
152 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Cut positions | 12 |
