Cub Cadet 2072
The Cub Cadet 2072 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 770 cc 46.98 ci engine. The rated power output is 20 hp 14.9 kW. Transmission: infinite forward and reverse.
Engine Power
20 hp
14.9 kW
Fuel & Capacities
4 gal
15.1 L
Transmission
infinite forward and reverse
Cub Cadet Lawn Tractors Cub Cadet 2072 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1987 - 1989
Garden tractor |
|---|---|
1987 - 1989 | |
Garden tractor | |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Garden tractor | |
Built in Brownsville, Tennessee, USA | |
Cub Cadet 2072 Engine | |
|---|---|
20HP Kohler 770cc 2-cyl gasoline | |
Fuel tank | 4 gal
15.1 L |
Engine details ...  | |
Cub Cadet 2072 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Power steering | |
Dual disc brakes | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | 0 OptOptional |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent OptOptional |
Clutch | electric |
Rear PTO Type | 2000 |
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 51.6 inches
131 cm |
Front tire | 18x8.50-8 |
Rear tire | 26x12.00-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 15 |
Battery volts | 12 |
References | |
|---|---|
 | |
Garden Tractors published in 1987, by Cub Cadet | |
Cub Cadet Garden Tractors published in 1988 | |
Cub Cadet Garden Tractors published in 1989 |
Engine
Engine Detail — 770 cc / 46.98 ci Gasoline
Manufacturer | Kohler M20S |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled horizontal-shaft opposed-twin |
Displacement | 770 cc
46.98 ci |
Bore/Stroke | 3.125x3.06 inches
79 x 78 mm |
Power (gross) | 20 hp
14.9 kW |
Idle RPM | 1200-3600 |
Starter | electric |
Starter volts | 12 |
Sparkplug | Chamption RBL-15Y |
Sparkplug gap | 0.025 inches
0.635 mm |
Intake valve clearance | 0.004 inches*Cold
0.102 mm |
Exhaust valve clearance | 0.012 inches*Cold
0.305 mm |
Oil capacity | 1.875 qts
1.8 L |
Oil change | 50 h |
Transmission
Transmission — infinite forward and reverse shaft-driven hydrostatic
Type | shaft-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 7 qts
6.6 L |
 | |
Dimensions
Cub Cadet 2072 Tires | |
|---|---|
Lawn/turf front | 18x8.50-8 |
Lawn/turf rear | 26x12.00-12 |
Dimensions | |
|---|---|
Wheelbase | 51.6 inches
131 cm |
Length | 78.5 inches
199 cm |
Width | 43.5 inches
110 cm |
Height (steering wheel) | 47.5 inches
120 cm |
Ground clearance | 7.6 inches
19 cm |
Front tread | 33 inches
83 cm |
Rear tread | 31.5 inches
80 cm |
Attachments
Attachment overview | |
|---|---|
50" mid-mount mower deck | |
60" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
Photos
Cub Cadet 2072
