Cub Cadet XT3 GSE
The Cub Cadet XT3 GSE is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 673 cc 41.1 ci engine. The listed engine power is Gasoline (gross): 22.5 hp / 16.8 kW. Transmission: Hydro-Gear BDU-10. Operating weight: 800 lbs 362 kg.
Engine Power
Gasoline (gross): 22.5 hp / 16.8 kW
Fuel & Capacities
3.3 gal
12.5 L
Transmission
Hydro-Gear BDU-10
Operating Weight
800 lbs
362 kg
Overview
 | 2015 - 2017
XT3 Enduro SeriesGarden tractor
XT3 Enduro Series
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Garden tractor | |
Original price was $4,300 in 2015 | |
Cub Cadet XT3 GSE Engine | |
|---|---|
22.5HP Kohler 673cc 2-cyl gasoline | |
Fuel tank | 3.3 gal
12.5 L |
Engine details ...  | |
Cub Cadet XT3 GSE Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | electric power |
Disc brakes | |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 50.6 inches
128 cm |
Weight | 800 lbs
362 kg |
Front tire | 16x6.5 |
Rear tire | 23x10.5 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | flywheel alternator |
Charging amps | 25 |
Battery CCA | 300 |
Battery volts | 12 |
References | |
|---|---|
 | |
New XT Enduro Series Lawn and Garden Tractors published in 2015, by Cub Cadet | |
Lawn and Garden Tractors published in 2016, by Cub Cadet |
Engine
Engine Detail — 673 cc / 41.1 ci Gasoline
Manufacturer | Kohler CH680 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled horizontal-shaft V-Twin |
Displacement | 673 cc
41.1 ci |
Bore/Stroke | 3.2x2.6 inches
81 x 66 mm |
Power (gross) | 22.5 hp
16.8 kW |
Starter | electric |
Starter volts | 12 |
Oil capacity | 1.9 qts
1.8 L |
Transmission
Transmission — Hydro-Gear BDU-10
Transmission | Hydro-Gear BDU-10 |
Type | shaft-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
Cub Cadet XT3 GSE Tires | |
|---|---|
Lawn/turf front | 16x6.5 |
Lawn/turf rear | 23x10.5 |
Dimensions | |
|---|---|
Wheelbase | 50.6 inches
128 cm |
Weight | 800 lbs
362 kg |
Front axle | Cast-iron |
Attachments
Attachment overview | |
|---|---|
42" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
42" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
2-blade with electric lift | |
Cutting width | 42 inches
106 cm |
Overall width | 50 inches
127 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Cut positions | 6 |
Photos
Cub Cadet XT3 GSE
Recommended Implements & Sizing Guide
Engineering recommendations for Cub Cadet Lawn Tractors Cub Cadet XT3 GSE based on its 22.5 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Cub Cadet Lawn Tractors Cub Cadet XT3 GSE.
Estimated Continuous Field Runtime: 2.8 hrs
Approximately 2.8 hours of continuous field operation at ~75% rated power on a full tank (3.3 gal / 12.5 L).
Estimated 75% Load Fuel Burn~1.2 gal/hr (4.4 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Cub Cadet Lawn Tractors Cub Cadet XT3 GSE Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Cub Cadet Lawn Tractors Cub Cadet XT3 GSE.
Converted Equivalents:
Horsepower (HP)22.5 hp
Kilowatts (kW)16.8 kW
Metric Horsepower (PS / CV)22.8 PS
