Deutz-Fahr 4046E Keyline

The Deutz-Fahr 4046E Keyline is a tractor produced by Deutz Fahr. It is equipped with a 164.8 ci 2.7 L engine. The listed engine power is Diesel (listed): 44.3 hp / 33.0 kW. Transmission: 8 forward and reverse. Operating weight: 4630 to 5512 pounds.

Overview

	2018 - 4E Keyline SeriesUtility tractor
2018 -
4E Keyline Series
Utility tractor

Production
Manufacturer	Deutz-Fahr
Utility tractor

Deutz-Fahr 4046E Keyline Engine
Simpson 2.7L 3-cyl diesel
Fuel tank	14.5 gal 54.9 L
Engine details ...

Deutz-Fahr 4046E Keyline Power
Engine	44.3 hp 33.0 kW

Mechanical
Two- or four-wheel drive
Differential lock	mechanical
Power steering
Open operator station. Two-post ROPS available.

Hydraulics
Type	open center
Valves	2 to 4
Pump flow	7.1 gpm 26.9 lpm

Tractor hitch
Rear Type	II
Rear lift	2756 lbs 1250 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540
	540/540E OptOptional
	540/1000 OptOptional

Dimensions & Tires
2WD Wheelbase	75.6 inches 192 cm
4WD Wheelbase	76.8 inches 195 cm
Weight	4630 to 5512 pounds
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
4E Keyline Series published in 2019, by Deutz-Fahr

Engine

Engine Detail — 164.8 ci / 2.7 L Diesel

Manufacturer	Simpson SJ327E
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	164.8 ci 2.7 L
Bore/Stroke	3.74x5.00 inches 95 x 127 mm
Emissions	Stage IIIA
Power	44.3 hp 33.0 kW
Rated RPM	2200
Torque	132.8 lb-ft 180.1 Nm
Starter	electric
Starter volts	12

Transmission

Transmission options
8-speed gear
12-speed creeper
8-speed partially synchronized

Transmission — 8 forward and 2 reverse gear

Type	gear
Gears	8 forward and 2 reverse
Clutch	mechanical dry disc

Transmission — 12 forward and 3 reverse creeper

Type	creeper
Gears	12 forward and 3 reverse
Clutch	mechanical dry disc

Transmission — 8 forward and reverse partially synchronized

Type	partially synchronized
Gears	8 forward and reverse
Clutch	mechanical dry disc

Dimensions

Deutz-Fahr 4046E Keyline Tires

Dimensions
2WD Wheelbase	75.6 inches 192 cm
4WD Wheelbase	76.8 inches 195 cm
Length	139.8 inches 355 cm
Width	70.9 inches 180 cm
Height (steering wheel)	64.3 inches 163 cm
2WD ROPS Weight	4630 lbs 2100 kg
4WD ROPS Weight	5512 lbs 2500 kg
2WD Front tread	57.6 inches 146 cm
4WD Front tread	58.6 inches 148 cm
Rear tread	56.7 inches 144 cm

Photos

Deutz-Fahr 4046E Keyline tractor photo
