Deutz-Fahr Agroplus 60

The Deutz-Fahr Agroplus 60 is a tractor produced by Deutz Fahr. It is equipped with a 186.72 ci 3.1 L engine. The listed engine power is Diesel (listed): 60 hp / 44.7 kW. Transmission: Synchrosplit. Operating weight: 5622 to 6394 pounds.

Engine Power

Diesel (listed): 60 hp / 44.7 kW

Fuel & Capacities

23.8 gal 90.1 L

Transmission

Synchrosplit

Operating Weight

5622 to 6394 pounds

Overview

	2001 - 2004 Agroplus SeriesUtility tractor Agroplus Series Utility tractor

Production
Manufacturer	Deutz-Fahr
Utility tractor

Deutz-Fahr Agroplus 60 Engine
Deutz 3.1L 3-cyl diesel
Fuel tank	23.8 gal 90.1 L
Engine details ...

Deutz-Fahr Agroplus 60 Power
Engine	60 hp 44.7 kW

Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Two-post ROPS in select markets. Deluxe and low-profile cabs available with optional air-conditioning.

Hydraulics
Type	open center
Valves	3
Pump flow	12.7 gpm 48.1 lpm

Tractor hitch
Rear Type	II
Rear lift	6393 lbs 2899 kg
Front Hitch	II
Front lift	3858 lbs 1749 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000
Front PTO	independent
Front PTO Type	1000

Dimensions & Tires
Wheelbase	83.2 inches 211 cm
Weight	5622 to 6394 pounds
Front tire	7.50-16
Rear tire	12.4R20
Full dimensions and tires ...

References

Agroplus published in 1996, by Deutz-Fahr
Agroplus 60 70 published in 2002, by Deutz-Fahr

Engine

Engine Detail — 186.72 ci / 3.1 L Diesel

Manufacturer	Deutz F3L913
Fuel Type	Diesel
Configuration	3-cylinder, air-cooled
Displacement	186.72 ci 3.1 L
Bore/Stroke	3.94x4.84 inches 100 x 123 mm
Power	60 hp 44.7 kW
Rated RPM	2400

Transmission

Transmission options
30-speed
45-speed three-speed power shift

Transmission — Synchrosplit

Transmission	Synchrosplit
Gears	30 forward and 15 reverse

Transmission — 45 forward and reverse three-speed power shift

Type	three-speed power shift
Gears	45 forward and reverse

Dimensions

Deutz-Fahr Agroplus 60 Tires
Ag front	7.50-16
	12.4R20 (4WD)
Ag rear	12.4R20
	14.9R30 (4WD)

Dimensions
Wheelbase	83.2 inches 211 cm
Length	151 inches 383 cm
Width	77.6 inches 197 cm
Height (cab)	95.7 inches 243 cm
2WD Weight	5622 lbs 2550 kg
4WD Weight	6394 lbs 2900 kg
Ground clearance	14 inches 35 cm

Recommended Implements & Sizing Guide

Engineering recommendations for Deutz Fahr Deutz-Fahr Agroplus 60 based on its 60 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	3 to 4 Bottom (16")3 - 4 铧 (40 cm)	Heavy Duty	Suitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing	6 ft (72 in)1.8 m	Medium Duty	Medium pasture clearing; rear slip-clutch recommended.
Rotary TillerSeedbed Prep	66 to 72 in165 - 180 cm	Medium Duty	Standard utility tiller; slip clutch protection required.
Disc HarrowSecondary Tillage	7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙	Medium Duty	Field leveling and clod breaking behind plows.
Hay BalerHay & Forage	4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机	Heavy Duty	Silage and dry hay; 540 RPM PTO with slip-clutch.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Deutz Fahr Deutz-Fahr Agroplus 60.

Estimated Continuous Field Runtime: 7.6 hrs

Approximately 7.6 hours of continuous field operation at ~75% rated power on a full tank (23.8 gal / 90.1 L).

Estimated 75% Load Fuel Burn~3.1 gal/hr (11.8 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Deutz Fahr Deutz-Fahr Agroplus 60 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Deutz Fahr Deutz-Fahr Agroplus 60.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)60 hp

Kilowatts (kW)44.7 kW

Metric Horsepower (PS / CV)60.8 PS
