Deutz-Fahr D 6507
The Deutz-Fahr D 6507 is a tractor produced by Deutz Fahr. It is equipped with a 230 ci 3.8 L engine. The listed engine power is Diesel (listed): 62 hp / 46.2 kW. Transmission: TW50.41. Operating weight: 6349 to 7055 pounds.
Engine Power
Diesel (listed): 62 hp / 46.2 kW
Fuel & Capacities
23.8 gal
90.1 L
Transmission
TW50.41
Operating Weight
6349 to 7055 pounds
Overview
 | 1982 - 1984
07 SeriesUtility tractor
07 Series
Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Deutz-Fahr |
Utility tractor | |
Deutz-Fahr D 6507 Engine | |
|---|---|
Deutz 3.8L 4-cyl diesel | |
Fuel tank | 23.8 gal
90.1 L |
Engine details ...  | |
Deutz-Fahr D 6507 Transmission | |
|---|---|
9-speed synchronized | |
Transmission details ...  |
Deutz-Fahr D 6507 Power | |
|---|---|
Engine | 62 hp
46.2 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Mechanical disc brakes | |
Four-post ROPS. Cab available with heat. |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2538 psi
175.0 bar |
Pump flow | 10.6 gpm
40.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift | 5300 lbs
2404 kg |
Front Hitch | I |
Front lift | 3372 lbs
1529 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
Front PTO | independent |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 84.3 inches
214 cm |
4WD Wheelbase | 86.2 inches
218 cm |
Weight | 6349 to 7055 pounds |
Front tire | 7.50-18 |
2WD Rear tire | 16.9-30 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
D5207C - D6507C - D7807C published by Deutz-Fahr | |
D6507C - D7007C - D7807C published by Deutz-Fahr |
Engine
Engine Detail — 230 ci / 3.8 L Diesel
Manufacturer | Deutz F4L 912 |
Fuel Type | Diesel |
Configuration | 4-cylinder, air-cooled |
Displacement | 230 ci
3.8 L |
Bore/Stroke | 3.94x4.72 inches
100 x 120 mm |
Power | 62 hp
46.2 kW |
Rated RPM | 2130 |
Starter type | electric |
Transmission
Transmission — TW50.41
Transmission | TW50.41 |
Type | synchronized |
Gears | 9 forward and 4 reverse |
With 16.9-30 rear tires. | |
 | |
Dimensions
Deutz-Fahr D 6507 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 7.50-18. Rear: 16.9-30 |
4WD Standard tires (ag) | Front: 10.5-20. Rear: 16.9-30 |
Dimensions | |
|---|---|
2WD Wheelbase | 84.3 inches
214 cm |
4WD Wheelbase | 86.2 inches
218 cm |
2WD Length | 144.1 inches
366 cm |
4WD Length | 140.6 inches
357 cm |
Width | 82.3 inches
209 cm |
Height | 97.6 inches
247 cm |
2WD Ground clearance | 19.3 inches
49 cm |
4WD Ground clearance | 12.8 inches
32 cm |
2WD Front tread | 59.1 to 74.8 inches
150 to 189 cm |
Deutz-Fahr D 6507 Weight | |
|---|---|
2WD Operating | 6349 lbs
2879 kg |
4WD Operating | 7055 lbs
3200 kg |
Max capacity | 8818 lbs
3999 kg |
Photos
Deutz-Fahr D 6507
Deutz-Fahr D 6507
Recommended Implements & Sizing Guide
Engineering recommendations for Deutz Fahr Deutz-Fahr D 6507 based on its 62 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | 4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机 | Heavy Duty | Silage and dry hay; 540 RPM PTO with slip-clutch. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Deutz Fahr Deutz-Fahr D 6507.
Estimated Continuous Field Runtime: 7.4 hrs
Approximately 7.4 hours of continuous field operation at ~75% rated power on a full tank (23.8 gal / 90.1 L).
Estimated 75% Load Fuel Burn~3.2 gal/hr (12.2 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Deutz Fahr Deutz-Fahr D 6507 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Deutz Fahr Deutz-Fahr D 6507.
Converted Equivalents:
Horsepower (HP)62 hp
Kilowatts (kW)46.2 kW
Metric Horsepower (PS / CV)62.9 PS
