Deutz-Fahr DX 6.30

The Deutz-Fahr DX 6.30 is a tractor produced by Deutz Fahr. It is equipped with a 373.9 ci 6.1 L engine. The listed engine power is Diesel (listed): 115 hp / 85.8 kW. Transmission: TW 904. Operating weight: 9700 to 10670 pounds.

Engine Power
Diesel (listed): 115 hp / 85.8 kW
Fuel & Capacities
31.7 gal 120.0 L
Transmission
TW 904
Operating Weight
9700 to 10670 pounds

Overview

Deutz-Fahr DX 6.30 tractor photo
1983 - 1990 DX6 SeriesRow-Crop tractor DX6 Series Row-Crop tractor
Production
Manufacturer
Deutz-Fahr
Row-Crop tractor
Deutz-Fahr DX 6.30 Engine
Deutz 6.1L 6-cyl diesel
Fuel tank
31.7 gal 120.0 L
58 gal*With optional tank. 219.5 L
Engine details ...
Deutz-Fahr DX 6.30 Power
Engine
115 hp 85.8 kW
PTO (claimed)
110 hp 82.0 kW
Mechanical
Two- or four-wheel drive
Differential lock
mechanical rear
OPTITRAC front
Power steering
Hydraulic dry disc brakes
Mastercab standard with air-conditioning.
Hydraulics
Type
open center
Pressure
2538 psi 175.0 bar
Valves
1 to 3
Pump flow
24 gpm 90.8 lpm
Tractor hitch
Rear Type
II
Rear lift (at ends)
11243 lbs 5099 kg
Power Take-off (PTO)
Rear PTO
independent
Rear PTO Type
540/1000 (1.375)
Engine RPM
540@2200
1000@2200
Front PTO
independent
Front PTO Type
1000
Dimensions & Tires
2WD Wheelbase
105.8 inches 268 cm
4WD Wheelbase
106.4 inches 270 cm
Weight
9700 to 10670 pounds
Front tire
11.00x16
2WD Rear tire
18.4x38
Full dimensions and tires ...
Electrical
Ground
negative
Charging system
alternator
Battery volts
12
References
DX 6.30 references literature
DX4.70-DX6.30-DX6.50-DX7.10 published in 1984, by Deutz-Fahr
DX6 published in 1983, by Deutz-Fahr

Engine

Engine Detail — 373.9 ci / 6.1 L Diesel

Manufacturer
Deutz F6L 913
Fuel Type
Diesel
Configuration
6-cylinder, air-cooled
Displacement
373.9 ci 6.1 L
Bore/Stroke
4.016x4.92 inches 102 x 125 mm
Power
115 hp 85.8 kW
Rated RPM
2400
Starter
electric
Starter volts
12
Oil capacity
16 qts 15.1 L

Transmission

Transmission options
15-speed fully synchronized
20-speed

Transmission — 15 forward and 5 reverse fully synchronized

Type
fully synchronized
Gears
15 forward and 5 reverse
Clutch
cerametallic disc
Oil capacity
50.7 qts 48.0 L
Five gears (1-5) in three ranges (L/M/H) plus reverse (R) range.

Transmission — TW 904

Transmission
TW 904
Gears
20 forward and 5 reverse
Five gears (1-5) in four ranges (LL/L/M/H) plus reverse (R) range.
With 18.4-38 rear tires.
DX 6.30 TW 904 speeds

Dimensions

Deutz-Fahr DX 6.30 Tires
2WD Standard tires (ag)
Front: 11.00x16. Rear: 18.4x38
4WD Standard tires (ag)
Front: 14.9x28. Rear: 18.4x38
Dimensions
2WD Wheelbase
105.8 inches 268 cm
4WD Wheelbase
106.4 inches 270 cm
Length
179.1 inches 454 cm
Width
90.5 inches 229 cm
2WD Height
107.3 inches 272 cm
4WD Height
112.2 inches 284 cm
2WD Weight
9700 lbs 4399 kg
4WD Weight
10670 lbs 4839 kg
Rear tread
64 to 88 inches 162 to 223 cm

Photos

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Deutz-Fahr DX 6.30

Recommended Implements & Sizing Guide

Engineering recommendations for Deutz Fahr Deutz-Fahr DX 6.30 based on its 115 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
4 to 5 Bottom (16-18")4 - 5 铧 (40-45 cm)Heavy DutyHeavy primary tillage; semi-mounted hitch recommended.
Rotary Cutter / MowerMowing & Clearing
10 to 12 ft Flex-Wing3.0 - 3.6 m 折叠双翼Heavy DutyWide swath pasture and crop residue shredding.
Rotary TillerSeedbed Prep
90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机Commercial / Field ScaleDeep intensive seedbed preparation for commercial row crops.
Disc HarrowSecondary Tillage
10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙Heavy DutyAggressive residue cutting in corn/cotton stubble.
Hay BalerHay & Forage
5x6 Round Baler or 3x3 Mid Square1.5x1.8 m 大圆捆或中型方捆机Heavy DutyHigh density baling; requires minimum 85 PTO HP.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Deutz Fahr Deutz-Fahr DX 6.30.

Estimated Continuous Field Runtime: 5.3 hrs

Approximately 5.3 hours of continuous field operation at ~75% rated power on a full tank (31.7 gal / 120 L).

Estimated 75% Load Fuel Burn~6 gal/hr (22.6 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Deutz Fahr Deutz-Fahr DX 6.30 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Deutz Fahr Deutz-Fahr DX 6.30.

Converted Equivalents:

Horsepower (HP)115 hp
Kilowatts (kW)85.8 kW
Metric Horsepower (PS / CV)116.6 PS
