Kubota M105D
The Kubota M105D is a tractor produced by Kubota. It is equipped with a 230 ci 3.8 L engine. The rated power output is 103.5 hp 77.2 kW. Transmission: 24 forward and reverse. Operating weight: 8025 lbs 3640 kg.
Engine Power
103.5 hp
77.2 kW
Fuel & Capacities
50.2 gal
190.0 L
Transmission
24 forward and reverse
Operating Weight
8025 lbs
3640 kg
Kubota M105D Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2005 - 2008
Grandom SeriesUtility tractor |
|---|---|
2005 - 2008 | |
Grandom Series | |
Utility tractor | |
Production | |
|---|---|
Manufacturer | Kubota |
Utility tractor | |
Kubota M105D Engine | |
|---|---|
Kubota 3.8L 4-cyl diesel | |
Fuel tank | 50.2 gal
190.0 L |
Engine details ...  | |
Kubota M105D Power | |
|---|---|
Engine | 103.5 hp
77.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and electronic draft control |
Rear lift | 6173 lbs
2800 kg |
8598 lbs*With optional lift cylinder.
3900 kg | |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Engine RPM | 540@2205 |
1000@2389 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 95.9 inches
243 cm |
Weight | 8025 lbs
3640 kg |
Front tire | 11.2-24 |
Rear tire | 16.9-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — 230 ci / 3.8 L Diesel
Manufacturer | Kubota V3800-TI |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 230 ci
3.8 L |
Bore/Stroke | 3.94x4.72 inches
100 x 120 mm |
Power | 103.5 hp
77.2 kW |
Fuel system | direct injection |
Rated RPM | 2600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
16-speed power shift | |
24-speed creeper |
Transmission — 16 forward and reverse power shift
Type | power shift |
Gears | 16 forward and reverse |
Clutch | hydraulic wet disc |
Eight power-shift gears in two ranges with shuttle. | |
 | |
Transmission — 24 forward and reverse creeper
Type | creeper |
Gears | 24 forward and reverse |
Optional creeper adds an additional 8-speed range to the standard transmission. | |
 | |
Dimensions
Kubota M105D Tires | |
|---|---|
Standard tires (ag) | Front: 11.2-24. Rear: 16.9-34 |
Dimensions | |
|---|---|
Wheelbase | 95.9 inches
243 cm |
Length | 159.5 inches
405 cm |
Width | 77.2 inches
196 cm |
Height | 104.3 inches
264 cm |
Weight | 8025 lbs
3640 kg |
Ground clearance | 17.9 inches
45 cm |
Front tread | 52.4 to 59.8 inches
133 to 151 cm |
Rear tread | 55.1 to 79.1 inches
139 to 200 cm |
