Fiat 1000 Super
The Fiat 1000 Super is a tractor produced by Fiat. It is equipped with a 335.6 ci 5.5 L engine. The listed engine power is Diesel (listed): 108.5 hp / 80.9 kW. Transmission: 16 forward and 4 reverse. Operating weight: 7561 to 8488 pounds.
Engine Power
Diesel (listed): 108.5 hp / 80.9 kW
Fuel & Capacities
30.4 gal
115.1 L
Transmission
16 forward and 4 reverse
Operating Weight
7561 to 8488 pounds
Overview
 | 1976 - 1979
Row-Crop tractor |
|---|
Production | |
|---|---|
Manufacturer | Fiat |
Row-Crop tractor | |
Variants | |
|---|---|
1000 Super | two-wheel drive |
1000DT Super | four-wheel drive |
Fiat 1000 Super Engine | |
|---|---|
Fiat 5.5L 6-cyl diesel | |
Fuel tank | 30.4 gal
115.1 L |
Engine details ...  | |
Fiat 1000 Super Power | |
|---|---|
Engine | 108.5 hp
80.9 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | inboard planetary |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Open operator station. Four-post ROPS and cab available. | |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 11.1 gpm
42.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and lower-link draft control |
Rear lift | 7056 lbs
3200 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2093 |
1000@2250 | |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 97.6 inches
247 cm |
4WD Wheelbase | 99.2 inches
251 cm |
Weight | 7561 to 8488 pounds |
Front tire | 7.50-20 |
2WD Rear tire | 16.9/14-38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
1000 super-1300 super Mark 4 published in 1979, by Fiat | |
1000 DT Super published in 1976, by Fiat | |
1000 Super |
Engine
Engine Detail — 335.6 ci / 5.5 L Diesel
Manufacturer | Fiat 8065.04 |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 335.6 ci
5.5 L |
Bore/Stroke | 4.06x4.33 inches
103 x 110 mm |
Power | 108.5 hp
80.9 kW |
Fuel system | direct injection |
Air cleaner | dry |
Compression | 17:1 |
Rated RPM | 2400 |
Firing order | 1-5-3-6-2-4 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
12-speed | |
16-speed creeper |
Transmission — 12 forward and 4 reverse
Gears | 12 forward and 4 reverse |
Clutch | 304.8mm dry disc |
Four gears in three ranges, plus reverse range. | |
With 16.9/14-38 rear tires. | |
 | |
Transmission — 16 forward and 4 reverse creeper
Type | creeper |
Gears | 16 forward and 4 reverse |
Optional creeper adds an additional range to the transmission. | |
With 16.9/14-38 rear tires. | |
 | |
Dimensions
Fiat 1000 Super Tires | |
|---|---|
2WD Standard tires (ag) | Front: 7.50-20. Rear: 16.9/14-38 |
4WD Standard tires (ag) | Front: 11.2/10-28. Rear: 16.9/14-38 |
Dimensions | |
|---|---|
2WD Wheelbase | 97.6 inches
247 cm |
4WD Wheelbase | 99.2 inches
251 cm |
2WD Length | 164.2 inches
417 cm |
4WD Length | 166.9 inches
423 cm |
2WD Width | 76 inches
193 cm |
4WD Width | 82.3 inches
209 cm |
Height (ROPS) | 105.1 inches
266 cm |
2WD Weight | 7561 lbs
3429 kg |
4WD Weight | 8488 lbs
3850 kg |
2WD Ground clearance | 22.4 inches
56 cm |
4WD Ground clearance | 16.9 inches
42 cm |
Photos
Fiat 1000 Super
Recommended Implements & Sizing Guide
Engineering recommendations for Fiat 1000 Super based on its 108.5 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 4 to 5 Bottom (16-18")4 - 5 铧 (40-45 cm) | Heavy Duty | Heavy primary tillage; semi-mounted hitch recommended. |
Rotary Cutter / MowerMowing & Clearing | 10 to 12 ft Flex-Wing3.0 - 3.6 m 折叠双翼 | Heavy Duty | Wide swath pasture and crop residue shredding. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙 | Heavy Duty | Aggressive residue cutting in corn/cotton stubble. |
Hay BalerHay & Forage | 5x6 Round Baler or 3x3 Mid Square1.5x1.8 m 大圆捆或中型方捆机 | Heavy Duty | High density baling; requires minimum 85 PTO HP. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Fiat 1000 Super.
Estimated Continuous Field Runtime: 5.4 hrs
Approximately 5.4 hours of continuous field operation at ~75% rated power on a full tank (30.4 gal / 115.1 L).
Estimated 75% Load Fuel Burn~5.6 gal/hr (21.4 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Fiat 1000 Super Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Fiat 1000 Super.
Converted Equivalents:
Horsepower (HP)108.5 hp
Kilowatts (kW)80.9 kW
Metric Horsepower (PS / CV)110 PS
