International Harvester 1086B

The International Harvester 1086B is a tractor produced by International Harvester. It is equipped with a 414 ci 6.8 L engine. The rated power output is 148 hp 110.4 kW. Transmission: two-speed power shift. Operating weight: 13117 lbs 5949 kg.

Engine Power
148 hp 110.4 kW
Transmission
two-speed power shift
Operating Weight
13117 lbs 5949 kg

International Harvester 1086B Serial Number & Year Decoder

Find the exact manufacture year of your tractor by checking your chassis serial number below.

Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.

Overview

International Harvester 1086B tractor photo
1981 - 1982 86B SeriesRow-Crop tractor
1981 - 1982
86B Series
Row-Crop tractor
Production
Manufacturer
International Harvester
Row-Crop tractor
Built in Geelong, Australia
Total built
164
International Harvester 1086B Engine
International Harvester 6.8L 6-cyl diesel
Engine details ...
International Harvester 1086B Transmission
16-speed Torque Amplifier
Transmission details ...
International Harvester 1086B Power
Engine
148 hp 110.4 kW
PTO (claimed)
98 hp 73.1 kW
Mechanical
Two- or four-wheel drive
Differential lock
electro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Cab standard.
Hydraulics
Type
open center
Tractor hitch
Rear Type
III/II
Power Take-off (PTO)
Rear PTO
independent
Rear PTO Type
540/1000 (1.375)
Engine RPM
540@2100
1000@2100
Dimensions & Tires
Weight
13117 lbs 5949 kg
Front tire
11.00-16
Rear tire
24.5-32
Full dimensions and tires ...
References
1086B references literature
International Harvester Australia: Geelong Works by Sarah Tomac*
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick
Technical Annual published in 1983, by Power Farming
*Publication contains known errors.

Engine

Engine Detail — 414 ci / 6.8 L Diesel

Manufacturer
International Harvester DT-414
Configuration
turbocharged diesel, 6-cylinder, liquid-cooled inline
Displacement
414 ci 6.8 L
Bore/Stroke
4.30x4.75 inches 109 x 121 mm
Power
148 hp 110.4 kW
Air cleaner
dry
Rated RPM
2400
Starter type
electric

Transmission

Transmission — two-speed power shift

Transmission
two-speed power shift
Type
Torque Amplifier
Gears
16 forward and 4 reverse
Clutch
hydraulic cerametallic disc

Dimensions

International Harvester 1086B Tires
Ag front
11.00-16
Ag rear
24.5-32
Dimensions
Length
168.1 inches 426 cm
Width
102 inches 259 cm
Shipping weight
13117 lbs 5949 kg
Ground clearance
15.4 inches 39 cm

Photos

International Harvester 1086B tractor photo

International Harvester 1086B tractor photo
