International Harvester 500C
The International Harvester 500C is a tractor produced by International Harvester. It is equipped with a 145.3 ci 2.4 L engine. The listed engine power is Diesel (listed): 44 hp / 32.8 kW; Gasoline (listed): 44 hp / 32.8 kW. Transmission: 4 forward and reverse. Drive type: crawler.
Engine Power
Diesel (listed): 44 hp / 32.8 kW; Gasoline (listed): 44 hp / 32.8 kW
Drive & Traction
crawler
Fuel & Capacities
Gasoline
Transmission
4 forward and reverse
Overview
 | 1969 - 1974
Agricultural Crawler tractor |
|---|
Production | |
|---|---|
Manufacturer | International Harvester |
Agricultural Crawler tractor | |
Built in Hamilton, Ontario, Canada | |
Variants | |
|---|---|
500C | ag crawler |
500C | industrial crawler |
500C Loader | loader-crawler |
International Harvester 500C Transmission | |
|---|---|
4-speed | |
Transmission details ...  |
International Harvester 500C Power | |
|---|---|
Engine | 44 hp
32.8 kW |
Mechanical | |
|---|---|
Drive | crawler |
Open operator station. | |
Dimensions & Tracks | |
|---|---|
Tracks | |
Full dimensions and tracks ...  |
References | |
|---|---|
 | |
Spring 1970 Buyer's Guide published by International Harvester | |
Spring 1971 Buyer's Guide published by International Harvester |
Engine
Engine options | |
|---|---|
International Harvester 2.5L 3-cyl diesel | |
International Harvester 2.4L 4-cyl gasoline |
Engine Detail — 155 ci / 2.5 L Diesel
Manufacturer | International Harvester D-155 |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 155 ci
2.5 L |
Bore/Stroke | 3.875x4.375 inches
98 x 111 mm |
Power | 44 hp
32.8 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Engine Detail — 145.3 ci / 2.4 L Gasoline
Manufacturer | International Harvester C-146 |
Fuel Type | Gasoline |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 145.3 ci
2.4 L |
Bore/Stroke | 3.375x4.06 inches
86 x 103 mm |
Power | 44 hp
32.8 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 4 forward and 1 reverse
Gears | 4 forward and 1 reverse |
Transmission — 4 forward and reverse
Gears | 4 forward and reverse |
Dimensions
International Harvester 500C Tracks |
|---|
Dimensions |
|---|
Photos
International Harvester 500C tractor photo
International Harvester 500C Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for International Harvester 500C.
Converted Equivalents:
Horsepower (HP)0 hp
Kilowatts (kW)0 kW
Metric Horsepower (PS / CV)0 PS
