International Harvester 533

The International Harvester 533 is a tractor produced by International Harvester. It is equipped with a 154.75 ci 2.5 L engine. The rated power output is 44.4 hp 33.1 kW. Transmission: Synchron. Operating weight: 4938 to 6107 pounds.

Overview

	1975 - 1989 33 SeriesUtility tractor
1975 - 1989
33 Series
Utility tractor

Production
Manufacturer	International Harvester
Utility tractor
Built in Neuss, Germany

Variants
533	utility
533V	vineyard

International Harvester 533 Engine
International Harvester 2.5L 3-cyl diesel
Engine details ...

International Harvester 533 Power
Engine	44.4 hp 33.1 kW

Mechanical
Two- or four-wheel drive
Steering	manual
Steering	power *Optional, available with four-wheel drive.
Open operator station. Cab optional.

Capacity
Fuel	15.85 gal 60.0 L
Hydraulic system	3.2 gal 12.1 L

Hydraulics
Type	open center
Capacity	3.2 gal 12.1 L
Pump flow	8.6 gpm 32.6 lpm

Tractor hitch
Rear Type	II
Rear lift	3969 lbs 1800 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540 (1.375)
	540/1000 (1.375)

Dimensions & Tires
2WD Wheelbase	81.5 inches 207 cm
4WD Wheelbase	79.9 inches 202 cm
Weight	4938 to 6107 pounds
Front tire	6.50-16
2WD Rear tire	14.9R28
Full dimensions and tires ...

Electrical
Charging system	alternator
Charging amps	33
Battery volts	12

References
Schmalspur-Plantagen-Schlepper published by International Harvester
533 published in 1975, by International Harvester

Engine

Engine Detail — 154.75 ci / 2.5 L Diesel

Manufacturer	International Harvester D-155
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	154.75 ci 2.5 L
Bore/Stroke	3.875x4.373 inches 98 x 111 mm
Power	44.4 hp 33.1 kW
Fuel system	direct injection
Rated RPM	2200
Torque	117.9 lb-ft 159.9 Nm
Torque RPM	1600
Starter volts	12
Oil capacity	6.9 qts 6.5 L
Coolant capacity	3.7 qts 3.5 L

Transmission

Transmission options
8-speed
16-speed
16-speed creeper

Transmission — 8 forward and 4 reverse

Gears	8 forward and 4 reverse
Four gears (1-4) in two ranges, plus reverse range.
With 14.9/13-28 rear tires.

Transmission — Synchron

Transmission	Synchron
Gears	16 forward and 8 reverse
Type	creeper
Gears	16 forward and 8 reverse

Dimensions

International Harvester 533 Tires
2WD Standard tires (ag)	Front: 6.50-16. Rear: 14.9R28
4WD Standard tires (ag)	Front: 10.5-18. Rear: 14.9R28

Dimensions
2WD Wheelbase	81.5 inches 207 cm
4WD Wheelbase	79.9 inches 202 cm
Length	134.7 inches 342 cm
Width	64.6 inches 164 cm
Height (cab)	94.1 inches 239 cm
2WD Clearance (front axle)	20.7 inches 52 cm
4WD Clearance (front axle)	12.6 inches 32 cm
2WD Front tread	48.3 to 69.5 inches 122 to 176 cm
4WD Front tread	54.1 to 63.9 inches 137 to 162 cm
Rear tread	56.2 to 75.9 inches 142 to 192 cm

International Harvester 533 Weight
2WD Open	4938 lbs 2239 kg
4WD Open	5578 lbs 2530 kg
2WD Cab	5467 lbs 2479 kg
4WD Cab	6107 lbs 2770 kg

Photos

International Harvester 533

International 533 Syncron.

International 533 Syncron.

International 533 Syncron.
