Iseki TA357

The Iseki TA357 is a tractor produced by Iseki. It is equipped with a 113.6 ci 1.9 L engine. The rated power output is 34.5 hp 25.7 kW. Transmission: 16 forward and reverse. Operating weight: 3770 lbs 1710 kg.

Overview

	1989 - 1992 Landleader TA7 SeriesCompact Utility tractor
1989 - 1992
Landleader TA7 Series
Compact Utility tractor

1989 - 1992
Landleader TA7 Series
Compact Utility tractor

Production
Manufacturer	Iseki
Compact Utility tractor

Iseki TA357 Engine
Isuzu 1.9L 4-cyl diesel
Fuel tank	12.7 gal 48.1 L
Engine details ...

Iseki TA357 Transmission
16-speed
Transmission details ...

Iseki TA357 Power
Engine	34.5 hp 25.7 kW

Mechanical
Four-wheel drive
Four-post ROPS. Cab optional.

Tractor hitch
Rear Type	JIS1

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	587@2600
	705@2600
	1057@2600
	1321@2600

Dimensions & Tires
Wheelbase	74.8 inches 189 cm
Weight	3770 lbs 1710 kg
Front tire	8-18
Rear tire	13.6-26
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Land Leader 7 Series published in 1991, by Iseki

Engine

	1989 - 1992 Landleader TA7 SeriesCompact Utility tractor
1989 - 1992
Landleader TA7 Series
Compact Utility tractor

1989 - 1992
Landleader TA7 Series
Compact Utility tractor

Engine Detail
Isuzu 4JE1
diesel
4-cylinder
liquid-cooled
Displacement	113.6 ci 1.9 L
Power	34.5 hp 25.7 kW
Rated RPM	2600
Starter	electric
Starter volts	12

Transmission

	1989 - 1992 Landleader TA7 SeriesCompact Utility tractor
1989 - 1992
Landleader TA7 Series
Compact Utility tractor

1989 - 1992
Landleader TA7 Series
Compact Utility tractor

Transmission
Gears	16 forward and reverse

Dimensions

	1989 - 1992 Landleader TA7 SeriesCompact Utility tractor
1989 - 1992
Landleader TA7 Series
Compact Utility tractor

1989 - 1992
Landleader TA7 Series
Compact Utility tractor

Iseki TA357 Tires
Standard tires (ag)	Front: 8-18. Rear: 13.6-26

Dimensions
Wheelbase	74.8 inches 189 cm
Length	129.9 inches 329 cm
Width	60 inches 152 cm
Height	92.1 inches 233 cm
Weight	3770 lbs 1710 kg
Ground clearance	14.2 inches 36 cm
Front tread	47.6 inches 120 cm
Rear tread	44.9 to 59.1 inches 114 to 150 cm

Photos

Iseki TA357 tractor photo
