Iseki TA607

The Iseki TA607 is a tractor produced by Iseki. It is equipped with a 169.1 ci 2.8 L engine. The rated power output is 59.2 hp 44.1 kW. Transmission: 16 forward and reverse. Operating weight: 4807 lbs 2180 kg.

Overview

	Landleader TA7 SeriesCompact Utility tractor
Landleader TA7 Series
Compact Utility tractor

Landleader TA7 Series
Compact Utility tractor

Production
Manufacturer	Iseki
Compact Utility tractor

Variants
1190	similar Massey Ferguson model

Iseki TA607 Engine
Isuzu 2.8L 4-cyl diesel
Fuel tank	13.5 gal 51.1 L
Engine details ...

Iseki TA607 Transmission
16-speed
Transmission details ...

Iseki TA607 Power
Engine	59.2 hp 44.1 kW

Mechanical
Four-wheel drive
Four-post ROPS. Cab optional.

Tractor hitch
Rear Type	JIS1

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	577@2500
	1038@2500

Dimensions & Tires
Wheelbase	79.9 inches 202 cm
Weight	4807 lbs 2180 kg
Front tire	8.3-20
Rear tire	12.4-32
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Land Leader 7 Series published in 1990, by Iseki*
*Publication contains known errors.

Engine

	Landleader TA7 SeriesCompact Utility tractor
Landleader TA7 Series
Compact Utility tractor

Landleader TA7 Series
Compact Utility tractor

Engine Detail
Isuzu 4JB1T
turbocharged diesel
4-cylinder
liquid-cooled
Displacement	169.1 ci 2.8 L
Bore/Stroke	3.661x4.016 inches 93 x 102 mm
Power	59.2 hp 44.1 kW
Rated RPM	2500
Starter	electric
Starter volts	12

Transmission

	Landleader TA7 SeriesCompact Utility tractor
Landleader TA7 Series
Compact Utility tractor

Landleader TA7 Series
Compact Utility tractor

Transmission
Gears	16 forward and reverse

Dimensions

	Landleader TA7 SeriesCompact Utility tractor
Landleader TA7 Series
Compact Utility tractor

Landleader TA7 Series
Compact Utility tractor

Iseki TA607 Tires
Standard tires (ag)	Front: 8.3-20. Rear: 12.4-32

Dimensions
Wheelbase	79.9 inches 202 cm
Length	136.6 inches 346 cm
Width	60.8 inches 154 cm
Height	94.5 inches 240 cm
Weight	4807 lbs 2180 kg
Ground clearance	14.6 inches 37 cm
Front tread	48 to 61.2 inches 121 to 155 cm
Rear tread	48 to 63.8 inches 121 to 162 cm

Photos

Iseki TA607 tractor photo
