Iseki TA607

The Iseki TA607 is a tractor produced by Iseki. It is equipped with a 169.1 ci 2.8 L engine. The listed engine power is Diesel (listed): 59.2 hp / 44.1 kW. Transmission: 16 forward and reverse. Operating weight: 4807 lbs 2180 kg.

Engine Power
Diesel (listed): 59.2 hp / 44.1 kW
Fuel & Capacities
13.5 gal 51.1 L
Transmission
16 forward and reverse
Operating Weight
4807 lbs 2180 kg

Overview

Iseki TA607 tractor photo
Landleader TA7 SeriesCompact Utility tractor
Landleader TA7 Series
Compact Utility tractor
Production
Manufacturer
Iseki
Compact Utility tractor
Variants
1190
similar Massey Ferguson model
Iseki TA607 Engine
Isuzu 2.8L 4-cyl diesel
Fuel tank
13.5 gal 51.1 L
Engine details ...
Iseki TA607 Transmission
16-speed
Transmission details ...
Iseki TA607 Power
Engine
59.2 hp 44.1 kW
Mechanical
Four-wheel drive
Four-post ROPS. Cab optional.
Tractor hitch
Rear Type
JIS1
Power Take-off (PTO)
Rear PTO Type
540 (1.375)
Engine RPM
577@2500
1038@2500
Dimensions & Tires
Wheelbase
79.9 inches 202 cm
Weight
4807 lbs 2180 kg
Front tire
8.3-20
Rear tire
12.4-32
Full dimensions and tires ...
Electrical
Ground
negative
Battery volts
12
References
TA607 references literature
Land Leader 7 Series published in 1990, by Iseki*
*Publication contains known errors.

Engine

Engine Detail — 169.1 ci / 2.8 L Diesel

Manufacturer
Isuzu 4JB1T
Configuration
turbocharged diesel, 4-cylinder, liquid-cooled
Displacement
169.1 ci 2.8 L
Bore/Stroke
3.661x4.016 inches 93 x 102 mm
Power
59.2 hp 44.1 kW
Rated RPM
2500
Starter
electric
Starter volts
12

Transmission

Transmission — 16 forward and reverse

Gears
16 forward and reverse

Dimensions

Iseki TA607 Tires
Standard tires (ag)
Front: 8.3-20. Rear: 12.4-32
Dimensions
Wheelbase
79.9 inches 202 cm
Length
136.6 inches 346 cm
Width
60.8 inches 154 cm
Height
94.5 inches 240 cm
Weight
4807 lbs 2180 kg
Ground clearance
14.6 inches 37 cm
Front tread
48 to 61.2 inches 121 to 155 cm
Rear tread
48 to 63.8 inches 121 to 162 cm

Photos

Iseki TA607 tractor photo

Iseki TA607 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Iseki TA607 based on its 59.2 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
3 to 4 Bottom (16")3 - 4 铧 (40 cm)Heavy DutySuitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing
6 ft (72 in)1.8 mMedium DutyMedium pasture clearing; rear slip-clutch recommended.
Rotary TillerSeedbed Prep
66 to 72 in165 - 180 cmMedium DutyStandard utility tiller; slip clutch protection required.
Disc HarrowSecondary Tillage
7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙Medium DutyField leveling and clod breaking behind plows.
Hay BalerHay & Forage
Small Square Baler (14x18")小方捆打捆机 (36x46 cm)Medium DutyClassic 2-string baler for horse and small livestock hay.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Iseki TA607.

Estimated Continuous Field Runtime: 4.4 hrs

Approximately 4.4 hours of continuous field operation at ~75% rated power on a full tank (13.5 gal / 51.1 L).

Estimated 75% Load Fuel Burn~3.1 gal/hr (11.7 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Iseki TA607 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki TA607.

Converted Equivalents:

Horsepower (HP)59.2 hp
Kilowatts (kW)44.1 kW
Metric Horsepower (PS / CV)60 PS

Direct Competitor Comparison

Compare Iseki TA607 against same-era industry alternatives in the same horsepower class.

Current Model
Iseki

Iseki TA607

Engine Power:Diesel (listed): 59.2 hp / 44.1 kW
★ Baseline Reference
DeereMarket Competitor

Deere 620

Engine Power:53.3
Production Years:1956 - 1958
New HollandMarket Competitor

New Holland T3040

Engine Power:53.5
Production Years:2007 - 2010
Massey FergusonMarket Competitor

Massey Ferguson 1754

Engine Power:53.6
Production Years:2013 - 2018
International HarvesterMarket Competitor

International Harvester 485

Engine Power:53.6
Production Years:1981 - 1985
