Iseki TD4410
The Iseki TD4410 is a tractor produced by Iseki. It is equipped with a 121.7 ci 2.0 L engine. The rated power output is 44 hp 32.8 kW. Transmission: 18 forward and 6 reverse. Operating weight: 3502 to 3789 pounds.
Engine Power
44 hp
32.8 kW
Fuel & Capacities
13.2 gal
50.0 L
Transmission
18 forward and 6 reverse
Operating Weight
3502 to 3789 pounds
Iseki TD4410 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | Compact Utility tractor | Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Iseki |
Compact Utility tractor | |
Iseki TD4410 Engine | |
|---|---|
Isuzu 2.0L 4-cyl diesel | |
Fuel tank | 13.2 gal
50.0 L |
Engine details ...  | |
Iseki TD4410 Transmission | |
|---|---|
18-speed synchromesh | |
Transmission details ...  |
Iseki TD4410 Power | |
|---|---|
Engine | 44 hp
32.8 kW |
PTO (claimed) | 38 hp
28.3 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Open operator station. Two-post fixed ROPS available. |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2275 psi
156.9 bar |
Pump flow | 8.45 gpm
32.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position and draft control |
Rear lift (at ends) | 3250 lbs
1474 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Engine RPM | 540@2250 |
1000@2250 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 76.3 inches
193 cm |
Weight | 3502 to 3789 pounds |
Front tire | 6.00-16 |
2WD Rear tire | 13.6-28 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Model TD4410 - TD4450 published by Iseki |
Engine
Engine Detail — 121.7 ci / 2.0 L Diesel
Manufacturer | Isuzu 4FC1 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 121.7 ci
2.0 L |
Bore/Stroke | 3.31x3.54 inches
84 x 90 mm |
Power | 44 hp
32.8 kW |
Air cleaner | dry |
Rated RPM | 2600 |
Torque | 90.4 lb-ft
122.6 Nm |
Torque RPM | 1400 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 18 forward and 6 reverse synchromesh
Type | synchromesh |
Gears | 18 forward and 6 reverse |
Clutch | 260mm dry disc |
Three gears, plus reverse in three ranges plus creeper range. | |
 | |
Dimensions
Iseki TD4410 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 6.00-16. Rear: 13.6-28 |
4WD Standard tires (ag) | Front: 8.00-18. Rear: 13.6-28 |
Dimensions | |
|---|---|
Wheelbase | 76.3 inches
193 cm |
Length | 134.2 inches
340 cm |
Width | 61.4 inches
155 cm |
Height | 86.6 inches
219 cm |
Height (steering wheel) | 57.8 inches
146 cm |
2WD Weight | 3502 lbs
1588 kg |
4WD Weight | 3789 lbs
1718 kg |
Ground clearance | 13.5 inches
34 cm |
Clearance (drawbar) | 12.25 inches
31 cm |
2WD Front tread | 45.3 to 61 inches
115 to 154 cm |
4WD Front tread | 43 to 63.8 inches
109 to 162 cm |
Rear tread | 48 to 63.8 inches
121 to 162 cm |
Photos
Iseki TD4410 tractor photo
Iseki TD4410 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki TD4410.
Converted Equivalents:
Horsepower (HP)44 hp
Kilowatts (kW)32.8 kW
Metric Horsepower (PS / CV)44.6 PS
