Iseki AT37
The Iseki AT37 is a tractor produced by Iseki. It is equipped with a 134.1 ci 2.2 L engine. The rated power output is 36.5 hp 27.2 kW. Transmission: 24 forward and reverse. Operating weight: 3660 to 4012 pounds.
Engine Power
36.5 hp
27.2 kW
Fuel & Capacities
13.2 gal
50.0 L
Transmission
24 forward and reverse
Operating Weight
3660 to 4012 pounds
Iseki AT37 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2004 - 2009
AT SeriesCompact Utility tractor |
|---|---|
2004 - 2009 | |
AT Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Iseki |
Compact Utility tractor | |
Iseki AT37 Engine | |
|---|---|
Iseki 2.2L 4-cyl diesel | |
Fuel tank | 13.2 gal
50.0 L |
Engine details ...  | |
Iseki AT37 Transmission | |
|---|---|
24-speed | |
Transmission details ...  |
Iseki AT37 Power | |
|---|---|
Engine | 36.5 hp
27.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Wet disc brakes | |
Two-post ROPS. Cab optional. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 586@2500 |
787@2500 | |
970@2500 | |
1263@2500 | |
-787@2500 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 76 inches
193 cm |
Weight | 3660 to 4012 pounds |
Front tire | 8-18 |
Rear tire | 13.6-26 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
AT published in 2008, by Iseki |
Engine
Engine Detail — 134.1 ci / 2.2 L Diesel
Manufacturer | Iseki E4CG |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 134.1 ci
2.2 L |
Bore/Stroke | 3.425x3.64 inches
87 x 92 mm |
Power | 36.5 hp
27.2 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 24 forward and reverse
Gears | 24 forward and reverse |
Clutch | dry disc |
Dimensions
Iseki AT37 Tires | |
|---|---|
Standard tires (ag) | Front: 8-18. Rear: 13.6-26 |
Dimensions | |
|---|---|
Wheelbase | 76 inches
193 cm |
Length | 138.6 inches
352 cm |
Width | 59.7 inches
151 cm |
Height (ROPS) | 88.6 inches
225 cm |
Height (cab) | 99.6 inches
252 cm |
ROPS Weight | 3660 lbs
1660 kg |
Cab Weight | 4012 lbs
1819 kg |
Ground clearance | 13.8 inches
35 cm |
Front tread | 49.2 inches
124 cm |
Rear tread | 44.9 to 59.1 inches
114 to 150 cm |
Photos
Iseki AT37 tractor photo
Iseki AT37 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki AT37.
Converted Equivalents:
Horsepower (HP)36.5 hp
Kilowatts (kW)27.2 kW
Metric Horsepower (PS / CV)37 PS
