Iseki TG353
The Iseki TG353 is a tractor produced by Iseki. It is equipped with a 121.9 ci 2.0 L engine. The listed engine power is Diesel (listed): 34.5 hp / 25.7 kW. Transmission: 16 forward and reverse. Operating weight: 3792 to 4178 pounds.
Engine Power
Diesel (listed): 34.5 hp / 25.7 kW
Fuel & Capacities
14.5 gal
54.9 L
Transmission
16 forward and reverse
Operating Weight
3792 to 4178 pounds
Overview
![]() | ???? - 2004
TG SeriesCompact Utility tractor |
|---|---|
???? - 2004 | |
TG Series | |
Compact Utility tractor | |
???? - 2004 | |
|---|---|
TG Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Iseki |
Compact Utility tractor | |
Iseki TG353 Engine | |
|---|---|
Iseki 2.0L 4-cyl diesel | |
Fuel tank | 14.5 gal
54.9 L |
Engine details ... | |
Iseki TG353 Transmission | |
|---|---|
16-speed | |
Transmission details ... |
Iseki TG353 Power | |
|---|---|
Engine | 34.5 hp
25.7 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Wet disc brakes | |
Two-post ROPS. Cab optional. |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 577/716/1038/1298 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 78.4 inches
199 cm |
Weight | 3792 to 4178 pounds |
Front tire | 8-18 |
Rear tire | 13.6-26 |
Full dimensions and tires ... | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
![]() | ???? - 2004
TG SeriesCompact Utility tractor |
|---|---|
???? - 2004 | |
TG Series | |
Compact Utility tractor | |
???? - 2004 | |
|---|---|
TG Series | |
Compact Utility tractor |
Engine Detail — 121.9 ci / 2.0 L Diesel
Manufacturer | Iseki E4CD |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 121.9 ci
2.0 L |
Power | 34.5 hp
25.7 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Transmission
![]() | ???? - 2004
TG SeriesCompact Utility tractor |
|---|---|
???? - 2004 | |
TG Series | |
Compact Utility tractor | |
???? - 2004 | |
|---|---|
TG Series | |
Compact Utility tractor |
Transmission — 16 forward and reverse
Gears | 16 forward and reverse |
Clutch | wet disc |
![]() | |
Dimensions
![]() | ???? - 2004
TG SeriesCompact Utility tractor |
|---|---|
???? - 2004 | |
TG Series | |
Compact Utility tractor | |
???? - 2004 | |
|---|---|
TG Series | |
Compact Utility tractor |
Iseki TG353 Tires | |
|---|---|
Standard tires (ag) | Front: 8-18. Rear: 13.6-26 |
Dimensions | |
|---|---|
Wheelbase | 78.4 inches
199 cm |
Length | 139.4 inches
354 cm |
Width | 60 inches
152 cm |
Height | 91.3 inches
231 cm |
ROPS Weight | 3792 lbs
1720 kg |
Cab Weight | 4178 lbs
1895 kg |
Ground clearance | 14.2 inches
36 cm |
Front tread | 49.2 inches
124 cm |
Rear tread | 44.9 to 59.1 inches
114 to 150 cm |
Recommended Implements & Sizing Guide
Engineering recommendations for Iseki TG353 based on its 34.5 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 5 ft (60 in)1.5 m | Medium Duty | Pasture maintenance and weeds up to 1.5" diameter. |
Rotary TillerSeedbed Prep | 54 to 60 in135 - 150 cm | Medium Duty | Thorough seedbed preparation in orchards and vegetable plots. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Iseki TG353.
Estimated Continuous Field Runtime: 8.1 hrs
Approximately 8.1 hours of continuous field operation at ~75% rated power on a full tank (14.5 gal / 54.9 L).
Estimated 75% Load Fuel Burn~1.8 gal/hr (6.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Iseki TG353 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki TG353.
Converted Equivalents:
Horsepower (HP)34.5 hp
Kilowatts (kW)25.7 kW
Metric Horsepower (PS / CV)35 PS
Direct Competitor Comparison
Compare Iseki TG353 against same-era industry alternatives in the same horsepower class.
Current Model
Iseki
Iseki TG353
Engine Power:Diesel (listed): 34.5 hp / 25.7 kW
★ Baseline Reference
General OrdnanceMarket Competitor
General Ordnance 14-28
Engine Power:31.1
Production Years:1919 - 1920
