Iseki TM3200

The Iseki TM3200 is a tractor produced by Iseki. It is equipped with a 68.5 ci 1.1 L engine. The rated power output is 19.2 hp 14.3 kW. Transmission: hydrostatic. Operating weight: 1433 to 1477 pounds.

Overview

	2004 - 2010 TM SeriesSub-Compact Utility tractor
2004 - 2010
TM Series
Sub-Compact Utility tractor

2004 - 2010
TM Series
Sub-Compact Utility tractor

Production
Manufacturer	Iseki
Sub-Compact Utility tractor

Iseki TM3200 Engine
Iseki 1.1L 3-cyl diesel
Fuel tank	6.6 gal 25.0 L
Engine details ...

Iseki TM3200 Transmission
6-speed gear
Transmission details ...

Iseki TM3200 Power
Engine	19.2 hp 14.3 kW
PTO (claimed)	16.5 hp 12.3 kW

Mechanical
Four-wheel drive
Differential lock	standard
Power steering
Mechanical wet disc brakes
ROPS

Hydraulics
Pressure	1993 psi 137.4 bar
Total flow	5.2 gpm 19.7 lpm
Steering flow	2.6 gpm 9.8 lpm
Steering press.	1494 psi 103.0 bar

Tractor hitch
Rear Type	I
Rear lift (at ends)	1190 lbs 539 kg

Power Take-off (PTO)
Gear Rear PTO Type	546
Hydro Rear PTO Type	565
Mid PTO Type	2000

Dimensions & Tires
Wheelbase	59.8 inches 151 cm
Weight	1433 to 1477 pounds
Front tire	5.00-12
Rear tire	8-18
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	40
Battery CCA	435
Battery volts	12

References
Iseki Product Guide published in 2005

Engine

	2004 - 2010 TM SeriesSub-Compact Utility tractor
2004 - 2010
TM Series
Sub-Compact Utility tractor

2004 - 2010
TM Series
Sub-Compact Utility tractor

Engine Detail
Iseki E3112
diesel
3-cylinder
liquid-cooled
Displacement	68.5 ci 1.1 L
Bore/Stroke	3.08x3.07 inches 78 x 78 mm
Power	19.2 hp 14.3 kW
Fuel system	indirect injection
Air cleaner	dry element
Compression	22.5:1
Rated RPM	2500
Firing order	1-3-2
Starter	electric
Starter volts	12
Oil capacity	2.9 qts 2.7 L
Coolant capacity	7.5 qts 7.1 L
Intake valve clearance	0.010 inches 0.254 mm
Exhaust valve clearance	0.010 inches 0.254 mm

Transmission

	2004 - 2010 TM SeriesSub-Compact Utility tractor
2004 - 2010
TM Series
Sub-Compact Utility tractor

2004 - 2010
TM Series
Sub-Compact Utility tractor

Transmission
Type	gear
Gears	6 forward and 2 reverse
Oil capacity	14.8 qts 14.0 L

Transmission
Transmission	hydrostatic
Gears	infinite forward and reverse
Oil capacity	14.8 qts 14.0 L

Speeds

Dimensions

	2004 - 2010 TM SeriesSub-Compact Utility tractor
2004 - 2010
TM Series
Sub-Compact Utility tractor

2004 - 2010
TM Series
Sub-Compact Utility tractor

Iseki TM3200 Tires
Ag front	5.00-12
Ag rear	8-18
Lawn/turf front	20.5x8.00-10
Lawn/turf rear	29x12.00-15

Dimensions
Wheelbase	59.8 inches 151 cm
Length	105.5 inches 267 cm
Width	47.6 inches 120 cm
Height (steering wheel)	50 inches 127 cm
Height (ROPS)	89.8 inches 228 cm
Hydro Ground clearance	9.6 inches 24 cm
Gear Ground clearance	11 inches 27 cm

Iseki TM3200 Weight
Gear	1433 lbs 650 kg
Hydro	1477 lbs 669 kg
Max capacity	3086 lbs 1399 kg
Max front axle	1433 lbs 650 kg
Max rear axle	1653 lbs 749 kg
