J.I. Case 730
The J.I. Case 730 is a tractor produced by J I Case. It is equipped with a 267 ci 4.4 L engine. Transmission: Dual-Range. Operating weight: 7,000 lbs 3175 kg.
Fuel & Capacities
31 gal
117.3 L
Transmission
Dual-Range
Operating Weight
7,000 lbs
3175 kg
J I Case J.I. Case 730 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1960 - 1969
730 SeriesStandard-tread tractor |
|---|---|
1960 - 1969 | |
730 Series | |
Standard-tread tractor | |
Production | |
|---|---|
Manufacturer | J.I. Case |
Standard-tread tractor | |
Built in Racine, Wisconsin, USA | |
Original price | $5,700 (1969) |
The Case 730 often refers to an entire series of tractors, with a number of engine and chassis options. The specific model 730 was the standard-tread diesel version of the Case 730 series. | |
Variants | |
|---|---|
730 | standard-front diesel |
731 | row-crop diesel |
732 | Western Special diesel |
733 | high-clearance diesel |
734 | orchard diesel |
740 | standard-front gas |
741 | row-crop gas |
742 | Western Special gas |
743 | high-clearance gas |
744 | orchard gas |
J.I. Case 730 Engine | |
|---|---|
J.I. Case 4.4L 4-cyl diesel | |
Engine details ...  |
J.I. Case 730 Power | |
|---|---|
PTO (claimed) | 56 hp
41.8 kW |
Plows | 5 |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
power optional | |
Open operator station. | |
Capacity | |
|---|---|
Fuel | 31 gal
117.3 L |
Hydraulic system | 17 gal
64.3 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 17 gal
64.3 L |
Valves | 4 |
Pump flow | 15.5 gpm
58.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 1,350 lbs
612 kg |
Type | Case Eagle Hitch |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
1000 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 102 inches
259 cm |
Weight | 7,000 lbs
3175 kg |
Front tire | 6.00-16 |
Rear tire | 14.9-30 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | generator |
Charging amps | 20 |
Batteries | 2 |
Battery CCA | 70 |
Battery volts | 6 |
References | |
|---|---|
 | |
295 / 391 / 392 Loaders published in 1966, by J.I. Case | |
1960 Progress Parade of Case Farm Equipment published by J.I. Case | |
A Complete New Line of Case Plus-Powered Tractors published in 1960, by J.I. Case | |
1965 Buyers Guide published by J.I. Case | |
Buyers Guide for '67 published in 1967, by J.I. Case |
Engine
Engine Detail — 267 ci / 4.4 L Diesel
Manufacturer | J.I. Case |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 267 ci
4.4 L |
Bore/Stroke | 4.125x5.00 inches
105 x 127 mm |
Compression | 15.2:1 |
Rated RPM | 1700 (Dual-Range) |
1900 (Case-o-Matic) | |
Firing order | 1-3-4-2 |
Starter volts | 12 |
Oil capacity | 9 qts
8.5 L |
Coolant capacity | 30 qts
28.4 L |
Transmission
Transmission options | |
|---|---|
8-speed torque converter | |
8-speed unsynchronized |
Transmission — Case-o-matic
Transmission | Case-o-matic |
Type | torque converter |
Gears | 8 forward and 2 reverse |
Transmission — Dual-Range
Transmission | Dual-Range |
Type | unsynchronized |
Gears | 8 forward and 2 reverse |
Clutch | mechanical dry disc |
Dimensions
J.I. Case 730 Tires | |
|---|---|
Ag front | 6.00-16 |
Ag rear | 14.9-30 |
Dimensions | |
|---|---|
Wheelbase | 102 inches
259 cm |
Length | 156 inches
396 cm |
Width | 88 inches
223 cm |
Height | 84 inches
213 cm |
Weight | 7,000 lbs
3175 kg |
Ground clearance | 15 inches
38 cm |
