John Deere 1635
The John Deere 1635 is a tractor produced by John Deere. It is equipped with a 179 ci 2.9 L engine. The listed engine power is Diesel (listed): 59.1 hp / 44.1 kW. Transmission: 8 forward and 4 reverse.
Engine Power
Diesel (listed): 59.1 hp / 44.1 kW
Fuel & Capacities
19.4 gal
73.4 L
Transmission
8 forward and 4 reverse
Overview
 | 1977 - 1979
Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | John Deere |
Utility tractor | |
Built in Getafe, Spain | |
John Deere 1635 Engine | |
|---|---|
John Deere 2.9L 3-cyl diesel | |
Fuel tank | 19.4 gal
73.4 L |
Engine details ...  | |
John Deere 1635 Transmission | |
|---|---|
8-speed gear | |
Transmission details ...  |
John Deere 1635 Power | |
|---|---|
Engine | 59.1 hp
44.1 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Power steering | |
Disc brakes | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live |
independent OptOptional | |
Rear PTO Type | 540 |
540/1000 | |
Dimensions & Tires | |
|---|---|
Front tire | 6.00-16 |
Rear tire | 13.6-28 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 33 |
Battery volts | 12 |
References | |
|---|---|
 | |
Tractores Fruteros y Vineros published in 1973, by John Deere |
Engine
Engine Detail — 179 ci / 2.9 L Diesel
Manufacturer | John Deere |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 179 ci
2.9 L |
Bore/Stroke | 4.19x4.33 inches
106 x 110 mm |
Power | 59.1 hp
44.1 kW |
Starter | electric |
Starter volts | 12 |
Oil capacity | 6.3 qts
6.0 L |
Transmission
Transmission — 8 forward and 4 reverse gear
Type | gear |
Gears | 8 forward and 4 reverse |
Dimensions
John Deere 1635 Tires | |
|---|---|
Ag front | 6.00-16 |
6.50-16 | |
7.50-16 | |
Ag rear | 13.6-28 |
14.9-28 | |
14.9-30 | |
16.9-3013.6-36 | |
13.6-38 | |
Dimensions |
|---|
Recommended Implements & Sizing Guide
Engineering recommendations for John Deere 1635 based on its 59.1 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere 1635.
Estimated Continuous Field Runtime: 6.3 hrs
Approximately 6.3 hours of continuous field operation at ~75% rated power on a full tank (19.4 gal / 73.4 L).
Estimated 75% Load Fuel Burn~3.1 gal/hr (11.6 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
John Deere 1635 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere 1635.
Converted Equivalents:
Horsepower (HP)59.1 hp
Kilowatts (kW)44.1 kW
Metric Horsepower (PS / CV)59.9 PS
Direct Competitor Comparison
Compare John Deere 1635 against same-era industry alternatives in the same horsepower class.
Current Model
John Deere
John Deere 1635
Engine Power:Diesel (listed): 59.1 hp / 44.1 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester 485
Engine Power:53.6
Production Years:1981 - 1985
