John Deere 6610

The John Deere 6610 is a tractor produced by John Deere. It is equipped with a 414 ci 6.8 L engine. The listed engine power is Diesel (listed): 114 hp / 85.0 kW; Diesel (listed): 4.1 hp / 3.1 kW. Transmission: John Deere PowrQuad. Operating weight: 10400 lbs 4717 kg.

Overview

	1997 - 2001 6000 TEN SeriesRow-Crop tractor 6000 TEN Series Row-Crop tractor

Production
Manufacturer	John Deere
Row-Crop tractor

John Deere 6610 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank	54.7 gal 207.0 L
Engine details ...

John Deere 6610 Transmission
24-speed
Transmission details ...

John Deere 6610 Power
Engine	114 hp 85.0 kW
PTO (claimed)	101 hp 75.3 kW

Mechanical
Four-wheel drive
Power steering
ROPS. Cab optional.

Hydraulics
Type	closed-center load sensing
Pressure	2900 psi 200.0 bar

Tractor hitch
Rear Type	II
Rear Arms	telescopic link ends

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000
Engine RPM	540@2143
	540E@1684
	1000@2208
Front PTO	independent
Front PTO Type	1000
Engine RPM	1000@2185

Dimensions & Tires
Wheelbase	104.3 inches 264 cm
Weight	10400 lbs 4717 kg
Front tire	16.9R26
Rear tire	18.4R38
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	90
	115
Battery volts	12

Engine

Engine Detail — 414 ci / 6.8 L Diesel

Manufacturer	John Deere
Configuration	turbocharged diesel, 6-cylinder
Displacement	414 ci 6.8 L
Bore/Stroke	4.19x5.00 inches 106 x 127 mm
Power	114 hp 85.0 kW
Rated RPM	2300
Torque	359 lb-ft 486.8 Nm
Torque RPM	1300
Firing order	1-5-3-6-2-4
Starter volts	12
Starter power	4.1 hp 3.1 kW
Oil capacity	20.8 qts 19.7 L
Coolant capacity	13.6 qts 12.9 L
	16.4 qts (cab) 15.5 L
Intake valve clearance	0.014 inches 0.356 mm
Exhaust valve clearance	0.018 inches 0.457 mm

Transmission

Transmission — John Deere PowrQuad

Transmission	John Deere PowrQuad
Gears	24 forward and reverse
40 kph transmission with 16.9-38 rear tires. Reverse speeds are about 15% faster than forward.

Dimensions

John Deere 6610 Tires
Ag front	16.9R26
Ag rear	18.4R38

Dimensions
Wheelbase	104.3 inches 264 cm
Length	178.5 inches 453 cm
Width	91.3 inches 231 cm
Height	110.6 inches 280 cm
Shipping weight	10400 lbs 4717 kg
Max weight	18,740 lbs 8500 kg
Clearance (front axle)	20.5 inches 52 cm
Front tread	63.5 to 83.2 inches 161 to 211 cm
Rear tread	63.5 to 84.2 inches 161 to 213 cm
