John Deere GX255

The John Deere GX255 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 675 cc 41.2 ci engine. The listed engine power is Gasoline (gross): 20 hp / 14.9 kW. Transmission: Tuff Torq K71C. Operating weight: 607 lbs 275 kg.

Engine Power
Gasoline (gross): 20 hp / 14.9 kW
Fuel & Capacities
2.75 gal 10.4 L
Transmission
Tuff Torq K71C
Operating Weight
607 lbs 275 kg

Overview

John Deere GX255 tractor photo
2004 - 2005 Garden tractor
Production
Manufacturer
John Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price was $6,099 in 2004
John Deere GX255 Engine
20HP Kawasaki 675cc 2-cyl gasoline
Fuel tank
2.75 gal 10.4 L
Engine details ...
John Deere GX255 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Power steering
Wet disc brakes
Open operator station.
Power Take-off (PTO)
Mid PTO
independent
Clutch
electric
Dimensions & Tires
Wheelbase
49 inches 124 cm
Weight
607 lbs 275 kg
Front tire
16x6.5-8
Rear tire
24x12-12
Full dimensions and tires ...
Electrical
Ground
negative
Battery CCA
500
Battery volts
12
References
GX255 references literature
Lawn and Garden Product Information Handbook published in 2004, by John Deere
Lawn and Garden Product Information Handbook published in 2005, by John Deere
Operator's Manual GX255 (OMM149668)
Operator's Manual GX255 (OMM152803) published in 2004
Premium Lawn and Garden Tractors published in 2004, by John Deere

Engine

Engine Detail — 675 cc / 41.2 ci Gasoline

Manufacturer
Kawasaki FH601V
Fuel Type
Gasoline
Configuration
2-cylinder, air-cooled vertical-shaft V-Twin
Displacement
675 cc 41.2 ci
Bore/Stroke
2.96x2.99 inches 75 x 76 mm
Power (gross)
20 hp 14.9 kW
Starter volts
12
Oil capacity
1.8 qts 1.7 L
Oil change
100 h
Sparkplug gap
0.030 inches 0.762 mm
John Deere GX255 Engine
John Deere GX255 engine image

Transmission

Transmission — Tuff Torq K71C

Transmission
Tuff Torq K71C
Type
belt-driven hydrostatic
Gears
infinite forward and reverse
Oil capacity
5.0 qts 4.7 L
Oil type
Low-Viscosity Hy-Gard
Oil change
250 h
GX255 K71C belt-driven hydrostatic speeds
Low-Viscosity Hy-Gard

Dimensions

John Deere GX255 Tires
Lawn/turf front
16x6.5-8
Lawn/turf rear
24x12-12
Dimensions
Wheelbase
49 inches 124 cm
Length
72 inches 182 cm
Width
40.8 inches (without mower) 103 cm
Height
47 inches 119 cm
Shipping weight
607 lbs 275 kg

Attachments

Attachment overview
48" mid-mount mower deck
54" mid-mount mower deck
Snowblower
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

Photos

John Deere GX255

John Deere GX255

John Deere GX255

John Deere GX255

Recommended Implements & Sizing Guide

Engineering recommendations for John Deere Lawn Tractors John Deere GX255 based on its 20 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
1 to 2 Bottom (12")1 - 2 铧 (30 cm)Light DutyIdeal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing
4 ft (48 in)1.2 mLight DutyPasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep
42 to 48 in105 - 120 cmLight DutyCovers compact tractor tire width.
Disc HarrowSecondary Tillage
5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)Light DutySmall acreage soil break-up and secondary aeration.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere Lawn Tractors John Deere GX255.

Estimated Continuous Field Runtime: 2.7 hrs

Approximately 2.7 hours of continuous field operation at ~75% rated power on a full tank (2.8 gal / 10.4 L).

Estimated 75% Load Fuel Burn~1 gal/hr (3.9 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

John Deere Lawn Tractors John Deere GX255 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere Lawn Tractors John Deere GX255.

Converted Equivalents:

Horsepower (HP)20 hp
Kilowatts (kW)14.9 kW
Metric Horsepower (PS / CV)20.3 PS
