Kubota GT-26

The Kubota GT-26 is a tractor produced by Kubota. It is equipped with a 91.5 ci 1.5 L engine. The rated power output is 25.6 hp 19.1 kW. Transmission: infinite forward and reverse (3-range). Operating weight: 2006 to 2094 pounds.

Overview

	2001 - 2002 GT SeriesCompact Utility tractor
2001 - 2002
GT Series
Compact Utility tractor

Production
Manufacturer	Kubota
Compact Utility tractor

Variants
GT-26	gear
GT-26F	hydrostatic
GT-26J	large tire

Kubota GT-26 Engine
Kubota 1.5L 3-cyl diesel
Fuel tank	7.4 gal 28.0 L
Engine details ...

Kubota GT-26 Power
Engine	25.6 hp 19.1 kW

Mechanical
Four-wheel drive
Two-post folding ROPS.

Tractor hitch
Rear Type	1

Power Take-off (PTO)
Rear PTO Type	540/750/1000 (1.375)

Dimensions & Tires
Wheelbase	59.1 inches 150 cm
Weight	2006 to 2094 pounds
Front tire	6-14
Rear tire	9.5-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Engine Detail — 91.5 ci / 1.5 L Diesel

Manufacturer	Kubota D1503
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	91.5 ci 1.5 L
Bore/Stroke	3.268x3.638 inches 83 x 92 mm
Power	25.6 hp 19.1 kW
Rated RPM	2600
Starter	electric
Starter volts	12

Transmission

Transmission options
12-speed
hydrostatic

Transmission — 12 forward and 4 reverse

Gears	12 forward and 4 reverse
Three gears (1-3), plus reverse, in four ranges (creeper and 1-3).

Transmission — infinite forward and reverse (3-range) hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse (3-range)

Dimensions

Kubota GT-26 Tires
Standard tires (ag)	Front: 6-14. Rear: 9.5-24
GT-26J Optional tires (ag)	Front: 7-14. Rear: 11.2-24

Dimensions
Wheelbase	59.1 inches 150 cm
Length	112.4 inches 285 cm
Width	46.7 inches 118 cm
Height (ROPS)	75.8 inches 192 cm
Height (cab)	76.2 inches 193 cm
Gear Weight	2006 lbs 909 kg
Hydro Weight	2094 lbs 949 kg
Ground clearance	13 inches 33 cm
Front tread	38.6 inches 98 cm
Rear tread	37.4 to 42.1 inches 94 to 106 cm

Photos

Kubota GT-26 tractor photo
