Kubota KL33

The Kubota KL33 is a tractor produced by Kubota. It is equipped with a 91.5 ci 1.5 L engine. The rated power output is 32.6 hp 24.3 kW. Transmission: 24 forward and 16 reverse. Operating weight: 2888 to 3274 pounds.

Overview

	1999 - 2005 KL SeriesCompact Utility tractor
1999 - 2005
KL Series
Compact Utility tractor

Production
Manufacturer	Kubota
Compact Utility tractor

Kubota KL33 Engine
Kubota 1.5L 3-cyl diesel
Fuel tank	10.6 gal 40.1 L
Engine details ...

Kubota KL33 Power
Engine	32.6 hp 24.3 kW

Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post ROPS. Cab optional.

Tractor hitch
Rear Type	I

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	561@2800
	791@2800
	980@2800
	1306@2800
	-980@2800

Dimensions & Tires
Wheelbase	68.7 inches 174 cm
Weight	2888 to 3274 pounds
Front tire	8-16
Rear tire	13.6-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Engine Detail — 91.5 ci / 1.5 L Diesel

Manufacturer	Kubota D1503
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	91.5 ci 1.5 L
Bore/Stroke	3.27x3.64 inches 83 x 92 mm
Power	32.6 hp 24.3 kW
Rated RPM	2800
Starter	electric
Starter volts	12

Transmission

Transmission options
16-speed
24-speed

Transmission — 16 forward and reverse

Gears	16 forward and reverse
Four gears (1-4) in two ranges with additional creeper range and shuttle shift.
Transmission
Gears	24 forward and 16 reverse
Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.

Dimensions

Kubota KL33 Tires
Standard tires (ag)	Front: 8-16. Rear: 13.6-24

Dimensions
Wheelbase	68.7 inches 174 cm
Length	125.2 inches 318 cm
Width	57.5 inches 146 cm
Height (ROPS)	78 inches 198 cm
Height (cab)	78.5 inches 199 cm
ROPS Weight	2888 lbs 1309 kg
Cab Weight	3274 lbs 1485 kg
Ground clearance	14.2 inches 36 cm
Front tread	44.5 inches 113 cm
Rear tread	43.7 to 62 inches 110 to 157 cm
