Massey Ferguson 1100

The Massey Ferguson 1100 is a tractor produced by Massey Ferguson. It is equipped with a 320 ci 5.2 L engine. The rated power output is 90.29 hp 67.3 kW. Transmission: Multi-Power. Operating weight: 9000 to 11435 pounds.

Overview

	1964 - 1972 1000 SeriesRow-Crop tractor
1964 - 1972
1000 Series
Row-Crop tractor

Production
Manufacturer	Massey Ferguson
Row-Crop tractor
Original price was $7,700 in 1972

Massey Ferguson 1100 Power
Drawbar (claimed)	85 hp 63.4 kW
PTO (claimed)	94 hp 70.1 kW
Drawbar (tested)	84.61 hp 63.1 kW
PTO (tested)	93.94 hp 70.1 kW
Performance test details ...

Mechanical
Two-wheel drive
Final drives	planetary
Differential lock	hydraulic rear OptOptional
Power steering
Hydraulic wet disc brakes
Open operator station. Cab optional with available air-conditioning.

Capacity
Open Fuel	35 gal 132.5 L
Cab Fuel	50 gal 189.2 L
Hydraulic system	17 gal 64.3 L

Hydraulics
Type	closed center
Capacity	17 gal 64.3 L
Pressure	2745 psi 189.3 bar
Valves	1
Pump flow	20 gpm 75.7 lpm

Tractor hitch
Rear Type	II
Control	position and draft control
Rear lift (at 24"/610mm)	5200 lbs 2358 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	wet disc
Rear PTO Type	540/1000 (1.375)

Dimensions & Tires
Wheelbase	102 inches 259 cm
Weight	9000 to 11435 pounds
Front tire	7.50-18
Rear tire	15.5-38
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Gas Batteries	1
Diesel Batteries	2
Battery volts	12
Battery AH	96

References
MF Row Crop Tractors published in 1969, by Massey Ferguson
MF 1100 Series Tractor Product Information Manual published by Massey Ferguson

Engine

Engine options
Perkins 5.8L 6-cyl diesel
Waukesha 5.2L 6-cyl gasoline
Waukesha 5.2L 6-cyl LP gas

Engine Detail — 354 ci / 5.8 L Diesel

Manufacturer	Perkins A6.534
Fuel Type	Diesel
Configuration	6-cylinder, liquid-cooled inline
Displacement	354 ci 5.8 L
Bore/Stroke	3.875x5.00 inches 98 x 127 mm
Air cleaner	dry
Compression	16:1
Rated RPM	2200
Starter volts	12
Oil capacity	16 qts 15.1 L
Coolant capacity	22 qts 20.8 L

Engine Detail — 320 ci / 5.2 L Gasoline

Manufacturer	Waukesha F 320-G
Fuel Type	Gasoline
Configuration	6-cylinder, liquid-cooled
Displacement	320 ci 5.2 L
Bore/Stroke	4.125x4.00 inches 105 x 102 mm
Compression	7.6:1
Rated RPM	2200
Starter volts	12

Engine Detail — 320 ci / 5.2 L LP Gas

Manufacturer	Waukesha
Fuel Type	LP gas
Configuration	6-cylinder, liquid-cooled
Displacement	320 ci 5.2 L
Bore/Stroke	4.125x4.00 inches 105 x 102 mm
Compression	9:1

Transmission

Transmission options
12-speed two-speed power shift
6-speed gear

Transmission — Multi-Power

Transmission	Multi-Power
Type	two-speed power shift
Gears	12 forward and 4 reverse
Clutch	279.4mm dry disc
Three gears (1-3) plus reverse (R) in two ranges (low/high) with two-range Multi-Power power shift.

Transmission — 6 forward and 2 reverse gear

Type	gear
Gears	6 forward and 2 reverse

Dimensions

Massey Ferguson 1100 Tires
Ag front	7.50-18
Ag rear	15.5-38
Ag front	7.50-16
	11.00-16
Ag rear	18.4-34
	18.4-38
	23.1-34

Dimensions
Wheelbase	102 inches 259 cm
Length	161.4 inches 409 cm
Width	106.3 inches 270 cm
Height (steering wheel)	74.6 inches 189 cm
Height (cab)	113.5 inches 288 cm
Ground clearance	17 inches 43 cm
Rear axle	3.25 inch diameter 82 mm
Front tread	56 to 80 inches 142 to 203 cm
Rear tread	60 to 96 inches 152 to 243 cm
Rear tread	60 to 120 inches 152 to 304 cm

Massey Ferguson 1100 Weight
Shipping	9000 lbs 4082 kg
Operating	9255 lbs (gas) 4198 kg
	11435 lbs (diesel) 5186 kg
Ballasted	14920 lbs 6767 kg

Tests

Tractor Tests
NTTL 923: diesel 12-speed 2WD
NTTL 963: gasoline 12-speed 2WD

Nebraska Tractor Test 923
Diesel 12-speed 2WD October 27 - November 1, 1965 Link: Nebraska Tractor Test 923 file
PTO performance
Power at rated engine speed	93.94 hp 70.1 kW
Fuel use	6.1 gal/hour 23.1 l/hour
Power at rated PTO speed	88.74 hp 66.2 kW
Fuel use	5.6 gal/hour 21.2 l/hour
Drawbar performance
Max power	84.61 hp 63.1 kW
Fuel use	6.2 gal/hour 23.5 l/hour
Gear 5 used for power test.
Max pull	11122 lbs 5044 kg
Gear 1L HP-High used for pull test.

Nebraska Tractor Test 963
Gasoline 12-speed 2WD June 17 - July 6, 1967 Link: Nebraska Tractor Test 963 file
PTO performance
Power at rated engine speed	90.29 hp 67.3 kW
Fuel use	8.3 gal/hour 31.4 l/hour
Power at rated PTO speed	83.62 hp 62.4 kW
Fuel use	7.6 gal/hour 28.8 l/hour
Drawbar performance
Max power	73.92 hp 55.1 kW
Fuel use	8.3 gal/hour 31.4 l/hour
Gear 5 used for power test.
Max pull	10184 lbs 4619 kg
Gear 1L HP-High used for pull test.

Photos

Massey Ferguson 1100
