Massey Ferguson 25195H

The Massey Ferguson 25195H is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 499 cc 30.5 ci engine. The listed engine power is Gasoline (gross): 19.5 hp / 14.5 kW. Transmission: Tuff Torq K46. Operating weight: 502 lbs 227 kg.

Engine Power

Gasoline (gross): 19.5 hp / 14.5 kW

Fuel & Capacities

3.5 gal 13.2 L

Transmission

Tuff Torq K46

Operating Weight

502 lbs 227 kg

Overview

	2010 - 2013 2500 SeriesLawn tractorSimplicity built 2500 Series Lawn tractor Simplicity built

Production
Distributor	Massey Ferguson
Manufacturer	Simplicity
Lawn tractor

Variants
Regent 19.5/38	similar Simplicity model

Massey Ferguson 25195H Engine
19.5HP Briggs & Stratton 499cc 1-cyl gasoline
Fuel tank	3.5 gal 13.2 L
Engine details ...

Massey Ferguson 25195H Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	50 inches 127 cm
Weight	502 lbs 227 kg
Front tire	15x6.0-6
Rear tire	20x8.0-8
Full dimensions and tires ...

Electrical
Ground	negative
Battery CCA	195
Battery volts	12

References

Lawn & Garden Equipment published in 2011, by Massey Ferguson

Engine

Engine Detail — 499 cc / 30.5 ci Gasoline

Manufacturer	Briggs & Stratton 31Q677
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Displacement	499 cc 30.5 ci
Bore/Stroke	3.57x3.06 inches 91 x 78 mm
Power (gross)	19.5 hp 14.5 kW
Rated RPM	3600
Starter	electric
Starter volts	12

Transmission

Transmission — Tuff Torq K46

Transmission	Tuff Torq K46
Type	belt-driven hydrostatic
Gears	infinite forward and reverse

Dimensions

Massey Ferguson 25195H Tires
Lawn/turf front	15x6.0-6
Lawn/turf rear	20x8.0-8

Dimensions
Wheelbase	50 inches 127 cm
Length	71 inches 180 cm
Width	37 inches 93 cm
Height (steering wheel)	45 inches 114 cm
Weight	502 lbs 227 kg
Front axle	Cast-iron
Rear axle	0.75 inch diameter 19 mm

Attachments

38" Mower deck
Type	mid-mount Massey Ferguson
	2-blade with manual lift
Cutting width	38 inches 96 cm
Overall width	50 inches 127 cm
Cut height	1 to 4 inch 2 to 10 cm
Cut positions	infinite

Photos

Massey Ferguson 25195H tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Massey Ferguson Lawn Tractors Massey Ferguson 25195H based on its 19.5 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Ferguson Lawn Tractors Massey Ferguson 25195H.

Estimated Continuous Field Runtime: 3.5 hrs

Approximately 3.5 hours of continuous field operation at ~75% rated power on a full tank (3.5 gal / 13.2 L).

Estimated 75% Load Fuel Burn~1 gal/hr (3.8 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Massey Ferguson Lawn Tractors Massey Ferguson 25195H Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Massey Ferguson Lawn Tractors Massey Ferguson 25195H.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)19.5 hp

Kilowatts (kW)14.5 kW

Metric Horsepower (PS / CV)19.8 PS
