Sabre 1542GS

The Sabre 1542GS is a tractor produced by Sabre Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The rated power output is 15 hp 11.2 kW. Transmission: Dana 4360. Operating weight: 396 lbs 179 kg.

Overview

	1998 Lawn tractor
1998
Lawn tractor

Production
Manufacturer	Sabre (a part of John Deere)
Lawn tractor
Built in Greeneville, Tennessee, USA

Sabre 1542GS Engine
15HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank	1.25 gal 4.7 L
Engine details ...

Sabre 1542GS Transmission
5-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual

Dimensions & Tires
Wheelbase	44.7 inches 113 cm
Weight	396 lbs 179 kg
Front tire	15x6.50-6
Rear tire	20x8.0-8
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	3
Battery CCA	230
Battery volts	12
Battery Group	U1

References
Lawn & Grounds Care Sales Manual published in 1997, by John Deere*
Operator's Manual Sabre Lawn Tractors (OMGX10226) published in 1997
Operator's Manual Sabre Lawn Tractors (OMGX10143) published in 1997
*Publication contains known errors.

Engine

Engine Detail — 465 cc / 28.4 ci Gasoline

Manufacturer	Briggs & Stratton 28N707
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Displacement	465 cc 28.4 ci
Bore/Stroke	3.44x3.06 inches 87 x 78 mm
Power (gross)	15 hp 11.2 kW
Air cleaner	paper and foam
Idle RPM	1750-3300
Starter	electric
Starter volts	12

Transmission

Transmission — Dana 4360

Transmission	Dana 4360
Type	belt-driven gear
Gears	5 forward and 1 reverse

Dimensions

Sabre 1542GS Tires
Lawn/turf front	15x6.50-6
Lawn/turf rear	20x8.0-8

Dimensions
Wheelbase	44.7 inches 113 cm
Length	60 inches 152 cm
Width	36 inches 91 cm
Height (steering wheel)	38.6 inches 98 cm
Weight	396 lbs 179 kg

Attachments

42" Mower deck
Type	mid-mount Sabre BG10109
	2-blade with manual lift
Cutting width	42 inches 106 cm
Cut height	1 to 4 inch 2 to 10 cm
