Snapper LT300
The Snapper LT300 is a tractor produced by Snapper Lawn Tractors. It is equipped with a 655 cc 40 ci engine. The rated power output is 22 hp 16.4 kW. Transmission: Tuff Torq K57. Operating weight: 590 lbs 267 kg.
Overview
 | 2012 - 2015
Lawn tractor |
|---|---|
2012 - 2015 | |
Lawn tractor | |
2012 - 2015 | |
|---|---|
Lawn tractor |
Production | |
|---|---|
Manufacturer | Snapper (a part of Briggs & Stratton) |
Lawn tractor | |
Snapper LT300 Engine | |
|---|---|
22HP Briggs & Stratton 655cc 2-cyl gasoline | |
Fuel tank | 4 gal
15.1 L |
Engine details ...  | |
Snapper LT300 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 53 inches
134 cm |
Weight | 590 lbs
267 kg |
Front tire | 15x6.00-6 |
Rear tire | 22x10.00-10 |
Full dimensions and tires ...  | |
Snapper LT300 attachments | |
|---|---|
46" mid-mount mower deck | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Product Catalog published in 2013, by Snapper |
Engine
| 2012 - 2015
Lawn tractor |
|---|---|
2012 - 2015 | |
Lawn tractor | |
2012 - 2015 | |
|---|---|
Lawn tractor |
Engine Detail | |
|---|---|
Briggs & Stratton 40H777 | |
gasoline | |
2-cylinder | |
air-cooled vertical-shaft V-Twin | |
Displacement | 655 cc
40 ci |
Bore/Stroke | 2.97x2.89 inches
75 x 73 mm |
Power (gross) | 22 hp
16.4 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 2012 - 2015
Lawn tractor |
|---|---|
2012 - 2015 | |
Lawn tractor | |
2012 - 2015 | |
|---|---|
Lawn tractor |
Transmission | |
|---|---|
Transmission | Tuff Torq K57 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Speeds | |
|---|---|
 |
Dimensions
| 2012 - 2015
Lawn tractor |
|---|---|
2012 - 2015 | |
Lawn tractor | |
2012 - 2015 | |
|---|---|
Lawn tractor |
Snapper LT300 Tires | |
|---|---|
Lawn/turf front | 15x6.00-6 |
Lawn/turf rear | 22x10.00-10 |
Dimensions | |
|---|---|
Wheelbase | 53 inches
134 cm |
Length | 71 inches
180 cm |
Width | 56 inches
142 cm |
Height | 43 inches
109 cm |
Weight | 590 lbs
267 kg |
Front axle | Cast-iron |
Rear axle | 0.75 inch diameter
19 mm |
Attachments
| 2012 - 2015
Lawn tractor |
|---|---|
2012 - 2015 | |
Lawn tractor | |
2012 - 2015 | |
|---|---|
Lawn tractor |
46" Mower deck | |
|---|---|
Type | mid-mount Snapper |
3-blade | |
Cutting width | 46 inches
116 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Cut positions | infinite |
Photos
Snapper LT300 tractor photo
