Snapper MGT1800G

The Snapper MGT1800G is a tractor produced by Snapper Lawn Tractors. It is equipped with a 624 cc 38.1 ci engine. The rated power output is 18 hp 13.4 kW. Transmission: 4 forward and 1 reverse. Operating weight: 1100 lbs 498 kg.

Overview

	1997 Garden tractorPower King built
1997
Garden tractor
Power King built

1997
Garden tractor
Power King built

Production
Distributor	Snapper
Manufacturer	Power King
Garden tractor
Built in Beaver Dam, Wisconsin, USA
The Snapper MGT1800G is the same as the Power King 1618GV.

Snapper MGT1800G Engine
18HP Kohler 624cc 2-cyl gasoline
Fuel tank	8.25 gal 31.2 L
Engine details ...

Snapper MGT1800G Transmission
4-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Final drives	spur bull gear
Steering	hydrostatic power
Mechanical band brakes
Open operator station.

Tractor hitch
Rear Type	0 OptOptional

Power Take-off (PTO)
Rear PTO	independent OptOptional
Rear PTO Type	2000
Front PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	58 inches 147 cm
Weight	1100 lbs 498 kg
Front tire	31.8x8.00-16
Rear tire	31.3x8.00-16
Full dimensions and tires ...

Snapper MGT1800G attachments
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...

MGT1800G Serial Numbers
Location:	Left side of main tractor frame.

Electrical
Ground	negative
Charging system	flywheel alternator
Charging amps	15
Battery volts	12
Battery AH	45

References
Snapper MGT1800G published in 1995

Engine

	1997 Garden tractorPower King built
1997
Garden tractor
Power King built

1997
Garden tractor
Power King built

Engine Detail
Kohler CH18
gasoline
2-cylinder
air-cooled horizontal-shaft V-Twin
Displacement	624 cc 38.1 ci
Bore/Stroke	3.03x2.64 inches 77 x 67 mm
Power (gross)	18 hp 13.4 kW
Starter	electric
Starter volts	12

Transmission

	1997 Garden tractorPower King built
1997
Garden tractor
Power King built

1997
Garden tractor
Power King built

Transmission
Type	shaft-driven gear
Gears	4 forward and 1 reverse

Speeds

Dimensions

	1997 Garden tractorPower King built
1997
Garden tractor
Power King built

1997
Garden tractor
Power King built

Snapper MGT1800G Tires
Ag front	21.2x4.00-12
Ag rear	31.8x8.00-16
	31.4x8.30-16
	31x15.50-15
Lawn/turf front	31.8x8.00-16
Lawn/turf rear	31.3x8.00-16
	31x13.50-15

Dimensions
Wheelbase	58 inches 147 cm
Length	84 inches 213 cm
Width	44 inches 111 cm
Height (steering wheel)	51 inches 129 cm
Weight	1100 lbs 498 kg
Ground clearance	15.75 inches 40 cm

Attachments

	1997 Garden tractorPower King built
1997
Garden tractor
Power King built

1997
Garden tractor
Power King built

Attachment overview
48" mid-mount mower deck
60" mid-mount mower deck
Snowblower
Blade
Front-end loader
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

Photos

Snapper MGT1800G tractor photo
