Snapper NXT 2652
The Snapper NXT 2652 is a tractor produced by Snapper Lawn Tractors. It is equipped with a 724 cc 44.18 ci engine. The rated power output is 26 hp 19.4 kW. Transmission: Tuff Torq K46.
Engine Power
26 hp
19.4 kW
Fuel & Capacities
3.5 gal
13.2 L
Transmission
Tuff Torq K46
Snapper Lawn Tractors Snapper NXT 2652 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2012 - 2013
NXT SeriesLawn tractor |
|---|---|
2012 - 2013 | |
NXT Series | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Snapper (a part of Briggs & Stratton) |
Lawn tractor | |
Original price was $2,999 in 2012 | |
Snapper NXT 2652 Engine | |
|---|---|
26HP Briggs & Stratton 724cc 2-cyl gasoline | |
Fuel tank | 3.5 gal
13.2 L |
Engine details ...  | |
Snapper NXT 2652 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 50 inches
127 cm |
Front tire | 15x6 |
Rear tire | 22x9.5 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 230 |
Battery volts | 12 |
References | |
|---|---|
 | |
Product Catalog published in 2013, by Snapper |
Engine
Engine Detail — 724 cc / 44.18 ci Gasoline
Manufacturer | Briggs & Stratton 44P777 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical shaft V-Twin |
Displacement | 724 cc
44.18 ci |
Bore/Stroke | 3.12x2.89 inches
79 x 73 mm |
Power (gross) | 26 hp
19.4 kW |
Starter | electric push button |
Starter volts | 12 |
Transmission
Transmission — Tuff Torq K46
Transmission | Tuff Torq K46 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
Snapper NXT 2652 Tires | |
|---|---|
Lawn/turf front | 15x6 |
Lawn/turf rear | 22x9.5 |
Dimensions | |
|---|---|
Wheelbase | 50 inches
127 cm |
Length | 71 inches
180 cm |
Width | 62 inches
157 cm |
Height | 45 inches
114 cm |
Front axle | Cast iron |
Attachments
Attachment overview | |
|---|---|
52" mid-mount mower deck | |
Snowblower | |
Blade |
52" Mower deck | |
|---|---|
Type | mid-mount Snapper |
3-blade with electric lift | |
Cutting width | 52 inches
132 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | infinite |
Photos
Snapper NXT 2652 tractor photo
