Snapper Z1804K

The Snapper Z1804K is a tractor produced by Snapper Lawn Tractors. It is equipped with a 691 cc 42.18 ci engine. The rated power output is 18 hp 13.4 kW. Transmission: Hydro-Gear. Operating weight: 778 lbs 352 kg.

Overview

	1995 Zero-turn mowerCountry Clipper built
1995
Zero-turn mower
Country Clipper built

1995
Zero-turn mower
Country Clipper built

Production
Distributor	Snapper
Manufacturer	Country Clipper
Zero-turn mower
Built in Corydon, Iowa, USA

Snapper Z1804K Engine
18HP Kohler 691cc 2-cyl gasoline
Fuel tank	5 gal 18.9 L
Engine details ...

Snapper Z1804K Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Disc brakes
Open operator station.

Dimensions & Tires
Wheelbase	49.5 inches 125 cm
Weight	778 lbs 352 kg
Front tire	13x5.00-6
Rear tire	20x10.00-10
Full dimensions and tires ...

Snapper Z1804K attachments
42" mid-mount mower deck
48" mid-mount mower deck
Attachment details ...

Electrical
Ground	negative
Charging amps	15
Battery CCA	250
Battery volts	12

References
Tractors & Z Riders published in 1995, by Snapper

Engine

	1995 Zero-turn mowerCountry Clipper built
1995
Zero-turn mower
Country Clipper built

1995
Zero-turn mower
Country Clipper built

Engine Detail
Kohler
gasoline
2-cylinder
air-cooled vertical-shaft
Displacement	691 cc 42.18 ci
Bore/Stroke	3.12x2.75 inches 79 x 70 mm
Power	18 hp 13.4 kW
Starter	electric
Starter volts	12
Oil capacity	2 qts 1.9 L

Transmission

	1995 Zero-turn mowerCountry Clipper built
1995
Zero-turn mower
Country Clipper built

1995
Zero-turn mower
Country Clipper built

Transmission
Transmission	Hydro-Gear
Type	hydrostatic
Gears	infinite forward and reverse

Speeds

Snapper Z1804K Transmission

Dimensions

	1995 Zero-turn mowerCountry Clipper built
1995
Zero-turn mower
Country Clipper built

1995
Zero-turn mower
Country Clipper built

Snapper Z1804K Tires
Lawn/turf front	13x5.00-6
Lawn/turf rear	20x10.00-10

Dimensions
Wheelbase	49.5 inches 125 cm
Length	75.5 inches 191 cm
Width	47 inches 119 cm
Height	41 inches 104 cm
Weight	778 lbs 352 kg

Attachments

	1995 Zero-turn mowerCountry Clipper built
1995
Zero-turn mower
Country Clipper built

1995
Zero-turn mower
Country Clipper built

Attachment overview
42" mid-mount mower deck
48" mid-mount mower deck

Photos

Snapper Z1804K tractor photo
