TYM T603

The TYM T603 is a tractor produced by Tym. It is equipped with a 135.2 ci 2.2 L engine. The listed engine power is Diesel (listed): 60 hp / 44.7 kW. Transmission: synchronized shuttle. Operating weight: 5204 to 5380 pounds.

Overview

	2006 - ???? Compact Utility tractor
2006 - ????
Compact Utility tractor

2006 - ????
Compact Utility tractor

Production
Manufacturer	TYM
Compact Utility tractor

TYM T603 Engine
Perkins 2.2L 4-cyl diesel
Engine details ...

TYM T603 Power
Engine	60 hp 44.7 kW
PTO (claimed)	46.6 hp 34.7 kW

Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post ROPS. Cab optional.

Capacity
Fuel	19 gal 71.9 L
Hydraulic system	11 gal 41.6 L

Hydraulics
Type	open center
Capacity	11 gal 41.6 L
Valves	3
Pump flow	10.4 gpm 39.4 lpm
Total flow	15.1 gpm 57.2 lpm
Steering flow	4.7 gpm 17.8 lpm

Tractor hitch
Rear Type	II
Control	position and draft control
Rear lift (at ends)	4270 lbs 1936 kg
Rear lift (at 24"/610mm)	3153 lbs 1430 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic
Rear PTO Type	540/1000 (1.375)

Dimensions & Tires
Wheelbase	83 inches 210 cm
Weight	5204 to 5380 pounds
Front tire	9.5-20
Rear tire	14.9-28
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	65
Battery volts	12

References
Major 4000 & Super Major 5000 Instruktionsbok published in 1965
4000 Major published in 1964
Operator's Manual LT600 Self Leveling Type Front Loader (LTS19-A160L) published in 2009

Engine

	2006 - ???? Compact Utility tractor
2006 - ????
Compact Utility tractor

2006 - ????
Compact Utility tractor

Engine Detail — 135.2 ci / 2.2 L Diesel

Manufacturer	Perkins 404D-22T
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Depending on market, this engine was also branded as a Caterpillar C2.2.
Displacement	135.2 ci 2.2 L
Bore/Stroke	3.3x3.9 inches 84 x 99 mm
Power	60 hp 44.7 kW
Fuel system	indirect injection
Air cleaner	dual dry element
Rated RPM	2600
Starter	electric
Starter volts	12
Oil capacity	7.1 qts 6.7 L
Coolant capacity	9.5 qts 9.0 L

TYM T603 Engine
Image courtesy of Cameron Penny

Transmission

	2006 - ???? Compact Utility tractor
2006 - ????
Compact Utility tractor

2006 - ????
Compact Utility tractor

Transmission options
24-speed
24-speed power shuttle

Transmission — synchronized shuttle

Transmission	synchronized shuttle
Gears	24 forward and reverse
Clutch	dry disc

Transmission — 24 forward and reverse power shuttle

Type	power shuttle
Gears	24 forward and reverse
Clutch	wet discs

Dimensions

	2006 - ???? Compact Utility tractor
2006 - ????
Compact Utility tractor

2006 - ????
Compact Utility tractor

TYM T603 Tires
Ag front	9.5-20
Ag rear	14.9-28
Lawn/turf front	31/13.5-15
Lawn/turf rear	540/648
Industrial front	12-16.5
Industrial rear	16.9-24

Dimensions
Wheelbase	83 inches 210 cm
Length	159 inches 403 cm
Width	71 inches 180 cm
Height	98 inches 248 cm
ROPS Weight	5204 lbs 2360 kg
Cab Weight	5380 lbs 2440 kg
Ground clearance	15.7 inches 39 cm

Attachments

	2006 - ???? Compact Utility tractor
2006 - ????
Compact Utility tractor

2006 - ????
Compact Utility tractor

Photos

TYM T603

TYM T603

TYM T603 with loader and backhoe.

TYM T603 with loader and backhoe.

TYM T603 with loader and backhoe.
