UTB/Universal 350

The UTB/Universal 350 is a tractor produced by Utb Universal. It is equipped with a 142.7 ci 2.3 L engine. The listed engine power is Diesel (listed): 35 hp / 26.1 kW. Transmission: 8 forward and 2 reverse. Operating weight: 3850 to 5263 pounds.

Overview

	1984 - 1991 Utility tractor

Production
Manufacturer	UTB/Universal
Utility tractor
Built in Brasov, Romania
Original price was $16,000 in 1991

Variants
350DTC	4WD

UTB/Universal 350 Engine
UTB 2.3L 3-cyl diesel
Fuel tank	11.9 gal 45.0 L
Engine details ...

UTB/Universal 350 Transmission
8-speed partially synchronized
Transmission details ...

UTB/Universal 350 Power
Engine	35 hp 26.1 kW

Mechanical
Two- or four-wheel drive
Final drives	spur gear
Differential lock	mechanical rear
Manual steering
Mechanical drum brakes
Open operator station.

Hydraulics
Type	open center
Valves	1
Pump flow	9.7 gpm 36.7 lpm

Tractor hitch
Rear Type	II/I
Rear lift	2650 lbs 1202 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540 (1.375)

Dimensions & Tires
Wheelbase	75.8 inches 192 cm
Weight	3850 to 5263 pounds
Front tire	6.00-16
2WD Rear tire	12.4-28
Full dimensions and tires ...

References
Universal Tractors published in 1987
Loaders published in 1987, by Universal

Engine

Engine Detail — 142.7 ci / 2.3 L Diesel

Manufacturer	UTB D-124
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	142.7 ci 2.3 L
Bore/Stroke	3.74x4.33 inches 95 x 110 mm
Power	35 hp 26.1 kW
Rated RPM	2200
Starter	electric
Starter volts	12

Transmission

Transmission — 8 forward and 2 reverse partially synchronized

Type	partially synchronized
Gears	8 forward and 2 reverse

Dimensions

UTB/Universal 350 Tires
2WD Standard tires (ag)	Front: 6.00-16. Rear: 12.4-28
4WD Standard tires (ag)	Front: 7.50-20. Rear: 12.4-28

Dimensions
Wheelbase	75.8 inches 192 cm
Length	116.3 inches 295 cm
Height (hood)	53.3 inches 135 cm
2WD Weight	3850 lbs 1746 kg
4WD Weight	5263 lbs 2387 kg
Ground clearance	18 inches 45 cm
2WD Front tread	50 to 77 inches 127 to 195 cm
4WD Front tread	55.3 inches 140 cm
Rear tread	47 to 75 inches 119 to 190 cm

Photos

Universal 350DTC with cab.
