Valmet 6850
The Valmet 6850 is a tractor produced by Valmet. It is equipped with a 268.4 ci 4.4 L engine. The rated power output is 118 hp 88.0 kW. Transmission: HiTech. Operating weight: 10251 lbs 4649 kg.
Engine Power
118 hp
88.0 kW
Fuel & Capacities
43.6 gal
165.0 L
Transmission
HiTech
Operating Weight
10251 lbs
4649 kg
Valmet 6850 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1998 - 2003
HiTech 6050 SeriesRow-Crop tractor |
|---|---|
1998 - 2003 | |
HiTech 6050 Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Valmet |
Row-Crop tractor | |
Original price | $65,000 |
Valmet 6850 Engine | |
|---|---|
Valmet 4.4L 4-cyl diesel | |
Fuel tank | 43.6 gal
165.0 L |
Engine details ...  | |
Valmet 6850 Transmission | |
|---|---|
36-speed three-speed power shift | |
Transmission details ...  |
Valmet 6850 Power | |
|---|---|
Engine | 118 hp
88.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Cab standard. |
Hydraulics | |
|---|---|
Pump flow | 19.3 gpm
73.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 15432 lbs
6999 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 91.6 inches
232 cm |
Weight | 10251 lbs
4649 kg |
Front tire | 14.9R28 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
Battery AH | 184 |
References | |
|---|---|
 | |
Modell-programmet 2000 published by Valtra | |
HiTech published in 1999, by Valtra | |
TwinTrac published in 2001, by Valtra |
Engine
Engine Detail — 268.4 ci / 4.4 L Diesel
Manufacturer | Valmet 420 DWRIE |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 268.4 ci
4.4 L |
Bore/Stroke | 4.25x4.72 inches
108 x 120 mm |
Power | 118 hp
88.0 kW |
Rated RPM | 2200 |
Torque | 361.4 lb-ft
490.1 Nm |
Torque RPM | 1400 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — HiTech
Transmission | HiTech |
Type | three-speed power shift |
Gears | 36 forward and reverse |
Four gears in three ranges with three-speed power shift and shuttle. | |
With 18.4R38 rear tires. | |
 | |
Dimensions
Valmet 6850 Tires | |
|---|---|
Standard tires (ag) | Front: 14.9R28. Rear: 18.4R38 |
Optional tires (ag) | Front: 480/65R28. Rear: 600/65R38 |
Dimensions | |
|---|---|
Wheelbase | 91.6 inches
232 cm |
Length | 178.3 inches
452 cm |
Width | 85.8 inches
217 cm |
Height (cab) | 110 inches
279 cm |
Height (exhaust) | 109.8 inches
278 cm |
Weight | 10251 lbs
4649 kg |
Clearance (front axle) | 20.1 inches
51 cm |
Clearance (rear axle) | 19.7 inches
50 cm |
Photos
Valmet 6850 tractor photo
