Valmet 903
The Valmet 903 is a tractor produced by Valmet. It is equipped with a 268.5 ci 4.4 L engine. The rated power output is 95.2 hp 71.0 kW. Transmission: Hi-Trac. Operating weight: 7981 to 8907 pounds.
Engine Power
95.2 hp
71.0 kW
Fuel & Capacities
23.8 gal
90.1 L
Transmission
Hi-Trac
Operating Weight
7981 to 8907 pounds
Valmet 903 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1979 - 1983
02 SeriesRow-Crop tractor |
|---|---|
1979 - 1983 | |
02 Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Valmet |
Row-Crop tractor | |
Valmet 903 Engine | |
|---|---|
Valmet 4.4L 4-cyl diesel | |
Engine details ...  |
Valmet 903 Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
Valmet 903 Power | |
|---|---|
Engine | 95.2 hp
71.0 kW |
PTO (claimed) | 91.2 hp
68.0 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Disc brakes | |
Cab standard with heater. | |
Capacity | |
|---|---|
Fuel | 23.8 gal
90.1 L |
Hydraulic system | 6.1 gal
23.1 L |
Hydraulics | |
|---|---|
Capacity | 6.1 gal
23.1 L |
Pressure | 3046 psi
210.0 bar |
Pump flow | 9.2 gpm
34.8 lpm |
Tractor hitch | |
|---|---|
Rear lift | 6393 lbs
2899 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@1556 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 92.1 inches
233 cm |
4WD Wheelbase | 96.3 inches
244 cm |
Weight | 7981 to 8907 pounds |
Front tire | 10.00-16 |
2WD Rear tire | 16.9-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Battery AH | 130 |
References | |
|---|---|
 | |
Trendsetter published in 1981, by Valmet | |
J60 - J71 - J81 published in 1980, by Valtra | |
VL1300 - VL1600 published in 1980, by Valtra |
Engine
Engine Detail — 268.5 ci / 4.4 L Diesel
Manufacturer | Valmet 411 CS |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 268.5 ci
4.4 L |
Bore/Stroke | 4.25x4.72 inches
108 x 120 mm |
Power | 95.2 hp
71.0 kW |
Rated RPM | 2200 |
Torque | 247.1 lb-ft
335.1 Nm |
Torque RPM | 1500 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 13.7 qts
13.0 L |
Coolant capacity | 16.9 qts
16.0 L |
Valmet 903 Engine | |
|---|---|
 |
Transmission
Transmission — Hi-Trac
Transmission | Hi-Trac |
Gears | 16 forward and 4 reverse |
Clutch | 310mm disc |
With 16.9-34 rear tires. | |
 | |
Dimensions
Valmet 903 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 10.00-16. Rear: 16.9-34 |
4WD Standard tires (ag) | Front: 13.6-28. Rear: 18.4-34 |
Dimensions | |
|---|---|
2WD Wheelbase | 92.1 inches
233 cm |
4WD Wheelbase | 96.3 inches
244 cm |
2WD Length | 153.7 inches
390 cm |
4WD Length | 164.2 inches
417 cm |
2WD Width | 77.6 inches
197 cm |
4WD Width | 83.1 inches
211 cm |
2WD Weight | 7981 lbs
3620 kg |
4WD Weight | 8907 lbs
4040 kg |
2WD Ground clearance | 18.9 inches
48 cm |
4WD Ground clearance | 18.5 inches
46 cm |
Valmet 903 Height | |
|---|---|
2WD Cab | 98.4 inches
249 cm |
4WD Cab | 103.2 inches
262 cm |
2WD Exhaust | 104.3 inches
264 cm |
4WD Exhaust | 106.3 inches
270 cm |
Attachments
Attachment overview | |
|---|---|
Valmet VL 1600 loader | |
Valmet J 60 loader | |
Valmet J 71 loader |
