Valmet 8150
The Valmet 8150 is a tractor produced by Valmet. It is equipped with a 402.6 ci 6.6 L engine. The rated power output is 123.4 hp 92.0 kW. Transmission: HiTech. Operating weight: 11220 lbs 5089 kg.
Engine Power
123.4 hp
92.0 kW
Fuel & Capacities
43.6 gal
165.0 L
Transmission
HiTech
Operating Weight
11220 lbs
5089 kg
Valmet 8150 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1995 - 2002
HiTech 8050 SeriesRow-Crop tractor |
|---|---|
1995 - 2002 | |
HiTech 8050 Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Valmet |
Row-Crop tractor | |
Built in Suolahti, Finland | |
Valmet 8150 Engine | |
|---|---|
SisuDiesel 6.6L 6-cyl diesel | |
Fuel tank | 43.6 gal
165.0 L |
Engine details ...  | |
Valmet 8150 Transmission | |
|---|---|
36-speed three-speed power shift | |
Transmission details ...  |
Valmet 8150 Power | |
|---|---|
Engine | 123.4 hp
92.0 kW |
Drawbar (tested) | 91.9 hp
68.5 kW |
PTO (tested) | 113.3 hp
84.5 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard. |
Hydraulics | |
|---|---|
Pressure | 2756 psi
190.0 bar |
Pump flow | 19.3 gpm
73.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 15432 lbs
6999 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
540/540E OptOptional | |
1000 OptOptional | |
Engine RPM | 540@1874 |
1000@2080 | |
540E@1539 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 100.7 inches
255 cm |
Weight | 11220 lbs
5089 kg |
Front tire | 14.9R28 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
Modell-programmet 2000 published by Valtra | |
HiTech published in 1999, by Valtra | |
TwinTrac published in 2001, by Valtra |
Engine
Engine Detail — 402.6 ci / 6.6 L Diesel
Manufacturer | SisuDiesel 620 DSRE |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled |
Displacement | 402.6 ci
6.6 L |
Bore/Stroke | 4.25x4.72 inches
108 x 120 mm |
Power | 123.4 hp
92.0 kW |
Rated RPM | 2200 |
Torque | 398 lb-ft
539.7 Nm |
Torque RPM | 1400 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — HiTech
Transmission | HiTech |
Type | three-speed power shift |
Gears | 36 forward and reverse |
Four gears in three ranges with three-speed power shift and power shuttle. | |
With 18.4R38 rear tires. | |
 | |
Dimensions
Valmet 8150 Tires | |
|---|---|
Ag front | 14.9R28 |
Ag rear | 18.4R38 |
Dimensions | |
|---|---|
Wheelbase | 100.7 inches
255 cm |
Length | 190.9 inches
484 cm |
Width | 85.8 inches
217 cm |
Height (cab) | 110 inches
279 cm |
Height (exhaust) | 110.4 inches
280 cm |
Weight | 11220 lbs
5089 kg |
Clearance (front axle) | 20.1 inches
51 cm |
Clearance (rear axle) | 19.7 inches
50 cm |
Tests
OCED Tractor Test 1618 | |
|---|---|
Diesel HiTech 4WD
February 1996 - March 1996,
Link: OCED Tractor Test 1618 file | |
PTO performance | |
Max power | 113.3 hp
84.5 kW |
Fuel use | 6.5 gal/hour
24.6 l/hour |
Power at rated engine speed | 109.3 hp
81.5 kW |
Fuel use | 6.9 gal/hour
26.1 l/hour |
Power at rated PTO speed | 111.8 hp
83.4 kW |
Fuel use | 6.7 gal/hour
25.4 l/hour |
Drawbar performance | |
Max power | 91.9 hp
68.5 kW |
Fuel use | 7.0 gal/hour
26.5 l/hour |
Max pull | 12240 lbs
5552 kg |
